APTM100A13SG

Share

Or copy the link below:

Mfr.Part #
APTM100A13SG
Manufacturer
Microchip Technology
Package / Case
SP6
Datasheet
Download
Description
MOSFET 2N-CH 1000V 65A SP6
Stock
23,637
In Stock :
23,637

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
Microchip Technology
Product Category :
Transistors - FETs, MOSFETs - Arrays
Height :
21.9mm
Factory Lead Time :
16 Weeks
Terminal Position :
UPPER
Number of Channels :
1
Terminal Form :
UNSPECIFIED
Continuous Drain Current (ID) :
65A
Resistance :
156mOhm
Radiation Hardening :
No
Width :
62mm
Drain to Source Voltage (Vdss) :
1000V 1kV
Mount :
Chassis Mount, Screw
Transistor Element Material :
SILICON
Fall Time (Typ) :
24 ns
Pin Count :
7
Number of Terminations :
7
JESD-609 Code :
e1
FET Type :
2 N-Channel (Half Bridge)
Gate to Source Voltage (Vgs) :
30V
Transistor Application :
SWITCHING
Vgs(th) (Max) @ Id :
5V @ 6mA
RoHS Status :
RoHS Compliant
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Length :
108mm
FET Technology :
METAL-OXIDE SEMICONDUCTOR
Input Capacitance (Ciss) (Max) @ Vds :
15200pF @ 25V
FET Feature :
Standard
Number of Pins :
6
Turn On Delay Time :
9 ns
Gate Charge (Qg) (Max) @ Vgs :
562nC @ 10V
Power Dissipation :
1.25kW
Case Connection :
Isolated
Published :
1999
Mounting Type :
Chassis Mount
JESD-30 Code :
R-XUFM-X7
Number of Elements :
2
Operating Mode :
ENHANCEMENT MODE
Packaging :
Bulk
Power - Max :
1250W
Lead Free :
Lead Free
Element Configuration :
Single
Pbfree Code :
yes
Turn-Off Delay Time :
50 ns
Rds On (Max) @ Id, Vgs :
156m Ω @ 32.5A, 10V
Terminal Finish :
TIN SILVER COPPER
Max Power Dissipation :
1.25kW
Rise Time :
9ns
Package / Case :
SP6
Operating Temperature :
-40°C~150°C TJ
Additional Feature :
AVALANCHE RATED
ECCN Code :
EAR99
Datasheets
APTM100A13SG
