Mfr.Part #
APTM100A13SCG
Manufacturer
Microchip Technology
Package / Case
SP6
Datasheet
Download
Description
MOSFET 2N-CH 1000V 65A SP6
Stock
43,937
In Stock :
43,937

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
Microchip Technology
Product Category :
Transistors - FETs, MOSFETs - Arrays
Vgs(th) (Max) @ Id :
5V @ 6mA
JESD-609 Code :
e1
JESD-30 Code :
R-XUFM-X7
Terminal Position :
UPPER
Qualification Status :
Not Qualified
FET Type :
2 N-Channel (Half Bridge)
Lifecycle Status :
IN PRODUCTION (Last Updated: 3 weeks ago)
Avalanche Energy Rating (Eas) :
1300 mJ
Peak Reflow Temperature (Cel) :
NOT SPECIFIED
Packaging :
Bulk
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Gate Charge (Qg) (Max) @ Vgs :
562nC @ 10V
Number of Pins :
6
Transistor Application :
SWITCHING
Number of Terminations :
7
Lead Free :
Lead Free
DS Breakdown Voltage-Min :
1000V
Transistor Element Material :
SILICON
Turn On Delay Time :
9 ns
Terminal Finish :
TIN SILVER COPPER
Turn-Off Delay Time :
50 ns
Mount :
Chassis Mount, Screw
Fall Time (Typ) :
24 ns
FET Technology :
METAL-OXIDE SEMICONDUCTOR
Continuous Drain Current (ID) :
65A
Gate to Source Voltage (Vgs) :
30V
Power - Max :
1250W
Number of Elements :
2
Package / Case :
SP6
Terminal Form :
UNSPECIFIED
Operating Mode :
ENHANCEMENT MODE
Power Dissipation :
1.25kW
ECCN Code :
EAR99
Pin Count :
7
Drain to Source Voltage (Vdss) :
1000V 1kV
Operating Temperature :
-40°C~150°C TJ
Mounting Type :
Chassis Mount
Input Capacitance (Ciss) (Max) @ Vds :
15200pF @ 25V
Additional Feature :
AVALANCHE RATED
Rds On (Max) @ Id, Vgs :
156m Ω @ 32.5A, 10V
Time@Peak Reflow Temperature-Max (s) :
NOT SPECIFIED
Case Connection :
Isolated
Pbfree Code :
yes
Max Power Dissipation :
1.25kW
RoHS Status :
RoHS Compliant
FET Feature :
Standard
Datasheets
APTM100A13SCG
Introducing Transistors - FETs, MOSFETs - Arrays Microchip Technology APTM100A13SCG from Chip IC,where excellence meets affordability. This product stands out with its Number of Pins:6, Number of Terminations:7, Package / Case:SP6, Operating Temperature:-40°C~150°C TJ, Mounting Type:Chassis Mount, APTM100A13SCG pinout, APTM100A13SCG datasheet PDF, APTM100A13SCG amp .Beyond Transistors - FETs, MOSFETs - Arrays Microchip Technology APTM100A13SCG ,we also offer SSM6N57NU,LF, DMN2004DMK-7, AO4629, Our vast inventory has you covered. Contact us now for immediate solutions.
