BD135

Share

Or copy the link below:

Mfr.Part #
BD135
Manufacturer
STMicroelectronics
Package / Case
TO-225AA, TO-126-3
Datasheet
Download
Description
TRANS NPN 45V 1.5A SOT32-3
Stock
1,842
In Stock :
1,842

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
STMicroelectronics
Product Category :
Transistors - Bipolar (BJT) - Single
Width :
2.7mm
Collector Emitter Breakdown Voltage :
45V
Weight :
4.535924g
Number of Elements :
1
Factory Lead Time :
8 Weeks
Length :
7.8mm
Polarity/Channel Type :
NPN
Collector Emitter Saturation Voltage :
500mV
Case Connection :
Isolated
Current - Collector Cutoff (Max) :
100nA ICBO
Lifecycle Status :
ACTIVE (Last Updated: 8 months ago)
Vce Saturation (Max) @ Ib, Ic :
500mV @ 50mA, 500mA
Number of Pins :
3
Height :
10.8mm
ECCN Code :
EAR99
Mount :
Through Hole
Transistor Element Material :
SILICON
Max Breakdown Voltage :
45V
hFE Min :
25
Base Part Number :
BD135
JESD-609 Code :
e3
Contact Plating :
Tin
Collector Emitter Voltage (VCEO) :
45V
Lead Free :
Lead Free
DC Current Gain (hFE) (Min) @ Ic, Vce :
40 @ 150mA 2V
REACH SVHC :
No SVHC
Emitter Base Voltage (VEBO) :
5V
Max Collector Current :
1.5A
Transition Frequency :
250MHz
Power Dissipation :
1.25W
Mounting Type :
Through Hole
Operating Temperature :
150°C TJ
Transistor Type :
NPN
Collector Base Voltage (VCBO) :
45V
Element Configuration :
Single
Max Power Dissipation :
1.25W
Pin Count :
3
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Package / Case :
TO-225AA, TO-126-3
Number of Terminations :
3
Transistor Application :
AMPLIFIER
RoHS Status :
ROHS3 Compliant
Radiation Hardening :
No
Packaging :
Tube
Datasheets
BD135
Introducing Transistors - Bipolar (BJT) - Single STMicroelectronics BD135 from Chip IC,where excellence meets affordability. This product stands out with its Number of Pins:3, Base Part Number:BD135, Mounting Type:Through Hole, Operating Temperature:150°C TJ, Package / Case:TO-225AA, TO-126-3, Number of Terminations:3, BD135 pinout, BD135 datasheet PDF, BD135 amp .Beyond Transistors - Bipolar (BJT) - Single STMicroelectronics BD135 ,we also offer BC817-40,235, BC817-40,215, BC807-40,215, Our vast inventory has you covered. Contact us now for immediate solutions.

STMicroelectronics BD135


NPN 150°C TJ 100nA ICBO 1 Elements 3 Terminations SILICON NPN TO-225AA, TO-126-3 Tube Through Hole

BD135 Description



BD135 transistor is an NPN transistor that operates by the current. Comparatively with Field-effect transistors with BD135 NPN transistor have a slower switching speed, while the input impedance is lower and they consume a lot of power. STMicroelectronics BD135 is widely used in television, broadcasting communications radar, computers electronic devices that control automatic devices as well as household appliances and other fields.



BD135 Features



Low rDS(on) Provides Higher Efficiency and Extends Battery Life

Miniature Surface Mount Package Saves Board Space

Pb-Free Package is Available

Automotive and Other Applications
