1778764
Or copy the link below:
- Mfr.Part #
- 1778764
- Manufacturer
- Phoenix Contact
- Package / Case
- Datasheet
- Download
- Description
- TERM BLOCK HDR 2POS 90DEG 2.5MM
- Stock
- 558
- In Stock ：
- 558
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Phoenix Contact
- Product Category :
- Headers, Plugs and Sockets
- Factory Lead Time :
- 4 Weeks
- Fastening Method :
- Connector
- Pitch :
- 0.098 2.50mm
- Insulation Height :
- 0.197 5.00mm
- Current :
- 6A
- RoHS Status :
- RoHS Compliant
- Series :
- COMBICON PTSM
- Voltage :
- 150V
- Feature :
- Board Guide, Pick and Place Cap, Solder Retention
- Published :
- 2011
- Number of Poles :
- 2
- Material Flammability Rating :
- UL94 V-0
- Type :
- Header, Male Pins, Shrouded (4 Side)
- Number of Decks :
- 1
- Number of Rows :
- 1
- Mount :
- Surface Mount
- Housing Material :
- Liquid Crystal Polymer (LCP)
- Voltage - Rated :
- 160V
- Termination Style :
- Solder
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Height :
- 5mm
- Header Orientation :
- 90°, Right Angle
- Orientation :
- RIGHT ANGLE
- Width :
- 6.7mm
- HTS Code :
- 8536.90.40.00
- Lead Free :
- Lead Free
- Packaging :
- Tape and Reel (TR)
- Flammability Rating :
- UL94 V-0
- Current Rating :
- 6A
- Depth :
- 7.5mm
- Pbfree Code :
- yes
- Contact Plating :
- Tin
- Mounting Type :
- Surface Mount
- Number of Levels :
- 1
- Color :
- Black
- Approval Agency :
- UL
- Length :
- 7.5mm
- Number of Ways :
- 2
- ECCN Code :
- EAR99
- Max Current Rating :
- 6A
- Datasheets
- 1778764
1778764 Documents
Tape & Reel (TR) 0.098 2.50mm Black 1 Levels Surface Mount Header, Male Pins, Shrouded (4 Side) COMBICON PTSM Liquid Crystal Polymer (LCP)
1778764 Overview
There is a Surface Mount mounting type for the device.This product is packaged in a case marked Tape & Reel (TR).Product number COMBICON PTSM belongs to the COMBICON PTSM Series.In many ways, it is more powerful due to its Board Guide, Pick and Place Cap, Solder Retention feature.There is a Surface Mount mount on the part.There are a lot of similarities between this part and other Header, Male Pins, Shrouded (4 Side) products.
1778764 Features
COMBICON PTSM series
1778764 Applications
There are a lot of Phoenix Contact
1778764 Terminal Blocks applications.
- Medical technology
- Military Technology
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
- Telecommunications
- Data Technology
- Blowers
- Control panels
- Electrical substations
