MRF16006

Manufacturer :

MACOM Technology Solutions

Product Category :

Transistors - Bipolar (BJT) - RF

DC Current Gain-Min (hFE) :

20

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Frequency - Transition :

-

Qualification Status :

Not Qualified

Gain :

7.4dB

Noise Figure (dB Typ @ f) :

-

Surface Mount :

yes

Pin Count :

2

DC Current Gain (hFE) (Min) @ Ic, Vce :

20 @ 200mA, 5V

Transistor Application :

AMPLIFIER

Power Dissipation-Max (Abs) :

26 W

Terminal Form :

Flat

Product Status :

Active

Mounting Type :

Chassis Mount

Pbfree Code :

yes

Number of Elements :

1

Reach Compliance Code :

Compliant

Series :

-

Polarity/Channel Type :

NPN

Transistor Type :

NPN

Transistor Element Material :

SILICON

Package / Case :

395C-01

Configuration :

Single

Manufacturer :

MACOM

Power - Max :

6W

Package Shape :

RECTANGULAR

Highest Frequency Band :

L BAND

Number of Terminals :

2

Current - Collector (Ic) (Max) :

1A

Voltage - Collector Emitter Breakdown (Max) :

55V

Subcategory :

Other Transistors

Supplier Device Package :

395C-01, Style 2

Additional Feature :

WITH EMITTER BALLASTING RESISTOR

JESD-30 Code :

R-CDFM-F2

Package :

Tray

Case Connection :

Base

Collector Current-Max (IC) :

1 A

Terminal Position :

Dual
