M30-6000746

Manufacturer :

Harwin

Product Category :

Headers, Male Pins

Contact Finish - Mating :

Tin

Insulation Color :

Natural

ECCN Code :

EAR99

DIN Conformance :

No

Contact Material :

Brass

Number of Rows :

1

Feature :

Board Guide, Solder Retention

MIL Conformance :

No

Number of Conductors :

ONE

HTS Code :

8536.69.40.40

Reliability :

COMMERCIAL

Body Length or Diameter :

0.394 inch

Pitch - Mating :

0.049 1.25mm

Contact Type :

Male Pin

RoHS Status :

ROHS3 Compliant

Insulation Material :

Polyamide (PA6T), Nylon 6T

Polarization Key :

POLARIZED HOUSING

Filter Feature :

No

Number of Positions :

7

Style :

Board to Cable/Wire

Contact Finish Thickness - Mating :

80.0μin 2.03μm

Mixed Contacts :

No

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

IEC Conformance :

No

Total Number of Contacts :

7

Current Rating (Amps) :

1A per Contact

Insulation Height :

0.189 4.80mm

Option :

GENERAL PURPOSE

Operating Temperature :

-25°C~85°C

Number of Positions Loaded :

All

Published :

2009

Voltage - Rated :

150V

PCB Contact Pattern :

RECTANGULAR

Mating Contact Pitch :

0.049 inch

Contact Shape :

Square

Material Flammability Rating :

UL94 V-0

Package / Case :

SIL

Mounting Type :

Surface Mount

Pbfree Code :

yes

Termination :

Solder

UL Flammability Code :

94V-0

Packaging :

Bulk

Fastening Type :

Detent Lock

Mount :

Surface Mount

Shrouding :

Shrouded - 4 Wall

Connector Type :

Header

Series :

M30

JESD-609 Code :

e3

Number Of PCB Rows :

1

Factory Lead Time :

13 Weeks
