282841-4

Manufacturer :

TE Connectivity AMP Connectors

Product Category :

Wire to Board

Wire Gauge :

12-30 AWG

Contact Plating :

Tin

Number of Decks :

1

Packaging :

Bulk

Screw Material - Plating :

Brass - Nickel Plated

Length :

20.32mm

ELV :

Compliant

Contact Material :

Brass

Max Supply Voltage (AC) :

300V

Mounting Type :

Through Hole

Flammability Rating :

UL94 V-0

Wire Termination :

Screw - Rising Cage Clamp

Wire/Cable Gauge :

30 AWG

Clamp Material - Plating :

Brass - Nickel Plated

Wire Gauge (Min) :

30 AWG

Voltage - Rated :

300V

Number of Ways :

2

Depth :

9mm

Number of Levels :

1

Contact Material - Plating :

Brass - Tin Plated

Termination :

Solder

Color :

Green

Terminal and Terminal Block Type :

MODULAR TERMINAL BLOCK

Lead Free :

Lead Free

ECCN Code :

EAR99

Factory Lead Time :

21 Weeks

Feature :

Interlocking (Side)

Radiation Hardening :

No

Number of Rows :

1

Series :

Buchanan

Pitch :

0.200 5.08mm

Mount :

Through Hole

RoHS Status :

RoHS Compliant

Min Operating Temperature :

-40°C

Current Rating :

17.5A

Screw Thread :

M3

Connector Type :

Receptacle

Number of Contacts :

4

Lifecycle Status :

ACTIVE (Last Updated: 5 days ago)

Max Voltage Rating (AC) :

300V

Safety Approval :

UL

REACH SVHC :

Unknown

Mating Orientation :

Horizontal with Board

Housing Material :

Polyamide (PA66), Nylon 6/6

Max Current Rating :

17.5A

Published :

2007

Wire Gauge (Max) :

30 AWG

Max Operating Temperature :

105°C

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Torque - Screw :

0.79 Nm (7.0 Lb-In)

Orientation :

Straight

Length - Tail :

3.5mm
