282805-2
Or copy the link below:
- Mfr.Part #
- 282805-2
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- TERM BLOCK PLUG 2POS STR 5MM
- Stock
- 952
- In Stock ：
- 952
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Plugs and Sockets
- Voltage - UL :
- 300V
- Packaging :
- Bulk
- Radiation Hardening :
- No
- Published :
- 2002
- Width :
- 18.4mm
- Factory Lead Time :
- 13 Weeks
- Contact Mating Finish :
- Tin
- Length :
- 10mm
- Series :
- Buchanan
- Insulation Height :
- 0.610 15.49mm
- Mounting Type :
- Free Hanging (In-Line)
- Thread Size :
- M3
- Connector Type :
- PLUG
- Torque - Screw :
- 0.79 Nm (7.0 Lb-In)
- Feature :
- Interlocking (Side), Retention Latches (Non-Wire Side)
- Operating Temperature :
- -40°C~110°C
- Depth :
- 15.5mm
- Max Current Rating :
- 15A
- Voltage - Rated :
- 300V
- Number of Positions :
- 2
- Wire Gauge (Max) :
- 30 AWG
- Positions Per Level :
- 2
- Orientation :
- RIGHT ANGLE
- Number of Positions Per Level :
- 2
- Gender :
- FEMALE
- Wire Gauge (Min) :
- 30 AWG
- Housing Color :
- Green
- Voltage - Rated AC :
- 300V
- Current :
- 15A
- Number of Contacts :
- 2
- Color :
- Green
- Material Flammability Rating :
- UL94 V-0
- Lead Free :
- Not Applicable
- Plug Wire Entry :
- 180°
- Number of Circuits :
- 2
- Current - UL :
- 15A
- Flammability Rating :
- UL94 V-0
- Number of Levels :
- 1
- Termination Style :
- Screw - Rising Cage Clamp
- Wire Strip Length :
- 6-7.5mm
- Wire Gauge or Range - AWG :
- 12-30 AWG
- Current Rating :
- 15A
- Voltage :
- 300V
- Number of Rows :
- 1
- ELV :
- Compliant
- Termination :
- Screw
- Housing Material :
- Polyamide (PA66), Nylon 6/6
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- RoHS Status :
- RoHS Compliant
- Number of Poles :
- 2
- Lifecycle Status :
- ACTIVE (Last Updated: 2 days ago)
- Contact Material :
- Phosphor Bronze
- Type :
- Plug, Female Sockets
- Wire Gauge or Range - mm² :
- 0.05-3mm2
- Material :
- Nylon
- Mount :
- Cable, Free Hanging
- Screw Size :
- M3
- Pitch :
- 0.197 5.00mm
- Contact Plating :
- Tin
- Datasheets
- 282805-2
Bulk 0.197 5.00mm Green 1 Levels Free Hanging (In-Line) Plug, Female Sockets Buchanan Polyamide (PA66), Nylon 6/6 Tin Phosphor Bronze
282805-2 Overview
The product is packaged in Plug.This device is mounted in the Free Hanging (In-Line) position.It has been determined that a Bulk case is necessary to package the product.There is a product in the Buchanan Series.There are a number of advantages to its Interlocking (Side), Retention Latches (Non-Wire Side) feature.Part Cable, Free Hanging is mounted to the part.It consists of circuits with a 2 value.As a result, the device runs at -40°C~110°C Operating Temperature.With this part, you get a lot of benefits that you won't find in other Plug, Female Sockets products.
282805-2 Features
Buchanan series
282805-2 Applications
There are a lot of TE Connectivity AMP Connectors
282805-2 Terminal Blocks applications.
- Military Technology
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
- Telecommunications
- Data Technology
- Blowers
- Control panels
- Electrical substations
- Energy efficient lighting (LED)
