282828-2
Or copy the link below:
- Mfr.Part #
- 282828-2
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- TERM BLOCK HDR 2POS VERT 10.16MM
- Stock
- 536
- In Stock ：
- 536
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Plugs and Sockets
- Number of Positions Per Level :
- 2
- Mixed Contacts :
- No
- Contact Tail Length :
- 0.138 3.50mm
- Contact Mating Finish :
- Tin
- Header Orientation :
- Vertical
- Current Rating :
- 15A
- Option :
- GENERAL PURPOSE
- Pitch :
- 0.400 10.16mm
- UL Flammability Code :
- 94V-0
- RoHS Status :
- RoHS Compliant
- Type :
- Header, Male Pins, Shrouded (4 Side)
- Contact Material :
- COPPER ALLOY
- Termination Style :
- Solder
- Lifecycle Status :
- ACTIVE (Last Updated: 2 weeks ago)
- Material Flammability Rating :
- UL94 V-0
- Mounting Type :
- Through Hole
- Connector Type :
- Header
- Series :
- Buchanan
- Mount :
- Through Hole
- Published :
- 2007
- Max Voltage Rating (AC) :
- 600V
- ELV :
- Compliant
- Shrouding :
- yes
- Lead Free :
- Lead Free
- Number of Rows :
- 2
- Length :
- 17.06mm
- Factory Lead Time :
- 12 Weeks
- Number of Positions :
- 2
- Total Number of Contacts :
- 20
- Radiation Hardening :
- No
- Max Current Rating :
- 15A
- Voltage :
- 600V
- IEC Conformance :
- No
- Width :
- 8.35mm
- Flammability Rating :
- UL94 V-0
- Housing Material :
- Polyamide (PA66), Nylon 6/6
- Filter Feature :
- No
- DIN Conformance :
- No
- Depth :
- 8.35mm
- Length - Tail :
- 3.5mm
- Number of Levels :
- 1
- Packaging :
- Bulk
- Insulation Height :
- 0.329 8.36mm
- Color :
- Green
- MIL Conformance :
- No
- Current :
- 15A
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Voltage - Rated :
- 600V
- Operating Temperature :
- -40°C~110°C
- Additional Feature :
- AMP-Latch
- Datasheets
- 282828-2
Bulk 0.400 10.16mm Green 1 Levels Through Hole Header, Male Pins, Shrouded (4 Side) Buchanan Polyamide (PA66), Nylon 6/6 Tin Copper Alloy
282828-2 Overview
The packaging contains Header.There is a Through Hole mounting type for the device.This product is packaged in a case marked Bulk.Product number Buchanan belongs to the Buchanan Series.Further, there are features such as AMP-LATCH, to name only a few.There is a Through Hole mount on the part.This device operates at a temperature of -40°C~110°C.There are a lot of similarities between this part and other Header, Male Pins, Shrouded (4 Side) products.
282828-2 Features
Buchanan series
282828-2 Applications
There are a lot of TE Connectivity AMP Connectors
282828-2 Terminal Blocks applications.
- Medical technology
- Military Technology
- Measuring & Control Technology
- Instrumentation
- Automotive Electronics
- Telecommunications
- Data Technology
- Blowers
- Control panels
- Electrical substations
