282821-3
Or copy the link below:
- Mfr.Part #
- 282821-3
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- TERM BLOCK HDR 3POS VERT 5MM
- Stock
- 28,165
- In Stock ：
- 28,165
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Plugs and Sockets
- MIL Conformance :
- No
- Number of Positions :
- 3
- IEC Conformance :
- No
- JESD-609 Code :
- e3
- Voltage :
- 300V
- Packaging :
- Bulk
- Operating Temperature :
- -40°C~110°C
- Contact Mating Finish :
- Tin
- Insulation Height :
- 0.472 12.00mm
- Mixed Contacts :
- No
- Max Voltage Rating (AC) :
- 300V
- Termination Style :
- Solder
- Mounting Type :
- Through Hole
- Current :
- 15A
- Filter Feature :
- No
- Number of Positions Per Level :
- 3
- Series :
- Buchanan
- RoHS Status :
- RoHS Compliant
- Housing Material :
- Polyamide (PA66), Nylon 6/6
- Feature :
- Interlocking (Side)
- Total Number of Contacts :
- 3
- Length - Tail :
- 3.5mm
- Connector Type :
- Header
- Flammability Rating :
- UL94 V-0
- Header Orientation :
- Vertical
- Pbfree Code :
- yes
- Radiation Hardening :
- No
- ECCN Code :
- EAR99
- Voltage - Rated AC :
- 300V
- Color :
- Green
- Max Current Rating :
- 15A
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Pitch :
- 0.197 5.00mm
- Current Rating :
- 15A
- Contact Tail Length :
- 0.138 3.50mm
- Contact Material :
- COPPER ALLOY
- Option :
- GENERAL PURPOSE
- Mount :
- Through Hole
- Factory Lead Time :
- 20 Weeks
- Number of Levels :
- 1
- DIN Conformance :
- No
- Number of Rows :
- 1
- Material Flammability Rating :
- UL94 V-0
- Additional Feature :
- STANDARD: IEC 998
- UL Flammability Code :
- 94V-0
- Published :
- 2005
- Type :
- Header, Male Pins, Shrouded (2 Side)
- Datasheets
- 282821-3
Bulk 0.197 5.00mm Green 1 Levels Through Hole Header, Male Pins, Shrouded (2 Side) Buchanan Polyamide (PA66), Nylon 6/6 Tin Copper Alloy
282821-3 Overview
Currently, it is packaged in Header.Mounting type Through Hole is assigned to the device.Packaging the product involves using a Bulk case.Among the products in the Buchanan Series, it is one of the most popular.There are also other features, like STANDARD: IEC 998, to name a few.A number of benefits can be derived from the Interlocking (Side) feature of this application.Through Hole is the mounting point for the part.-40°C~110°C Operating Temperature is used by the device.There are a lot of advantages this part has in common with other Header, Male Pins, Shrouded (2 Side) parts.
282821-3 Features
Buchanan series
282821-3 Applications
There are a lot of TE Connectivity AMP Connectors
282821-3 Terminal Blocks applications.
- Automotive Electronics
- Telecommunications
- Data Technology
- Blowers
- Control panels
- Electrical substations
- Energy efficient lighting (LED)
- LED municipal outdoor and street lighting
- All Electrical Machinery
- Refrigeration control
