282809-4

Manufacturer :

TE Connectivity AMP Connectors

Product Category :

Headers, Plugs and Sockets

Thread Size :

M3

Series :

Buchanan

Wire Strip Length :

6-7.5mm

Max Current Rating :

15A

Wire Gauge (Min) :

30 AWG

Screw Size :

M3

Lifecycle Status :

ACTIVE (Last Updated: 5 days ago)

Insulation Height :

0.610 15.49mm

Current :

15A

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Max Voltage Rating (AC) :

600V

Type :

Plug, Female Sockets

Number of Levels :

1

Number of Rows :

1

Contact Plating :

Tin

ELV :

Compliant

Termination Style :

Screw - Rising Cage Clamp

Housing Color :

Green

Voltage - UL :

600V

Pitch :

0.400 10.16mm

Voltage - Rated :

600V

Current - UL :

15A

Material Flammability Rating :

UL94 V-0

Color :

Green

Max Supply Voltage (AC) :

600V

Operating Temperature :

-40°C~110°C

Contact Mating Finish :

Tin

RoHS Status :

RoHS Compliant

Current Rating :

15A

Length :

35.56mm

Connector Type :

PLUG

Flammability Rating :

UL94 V-0

Depth :

18.4mm

Plug Wire Entry :

180°

Mounting Type :

Free Hanging (In-Line)

Voltage :

600V

Housing Material :

Polyamide (PA66), Nylon 6/6

Orientation :

RIGHT ANGLE

Published :

2006

Wire Gauge or Range - AWG :

12-30 AWG

Packaging :

Bulk

Number of Contacts :

4

Positions Per Level :

4

Min Operating Temperature :

-40°C

Number of Positions Per Level :

4

Mount :

Cable, Free Hanging

Factory Lead Time :

13 Weeks

Wire Gauge (Max) :

30 AWG

Termination :

Screw

Contact Material :

Phosphor Bronze

Number of Circuits :

4

Radiation Hardening :

No

Wire Gauge or Range - mm² :

0.05-3mm2

Feature :

Retention Latches (Non-Wire Side)

Torque - Screw :

0.79 Nm (7.0 Lb-In)

Lead Free :

Not Applicable

Max Operating Temperature :

105°C

Number of Positions :

4
