TEMD5020X01
Or copy the link below:
- Mfr.Part #
- TEMD5020X01
- Manufacturer
- Vishay
- Package / Case
- 4-SMD, No Lead
- Datasheet
- Download
- Description
- PHOTODIODE 430 TO 1100 NM
- Stock
- 7,341
- In Stock ：
- 7,341
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Vishay
- Product Category :
- Optical Sensors - Photodiodes
- Configuration :
- Single
- Height :
- 1.12mm
- Viewing Angle :
- 130°
- JESD-609 Code :
- e3
- Diode Type :
- Pin
- Fall Time (Typ) :
- 100 ns
- Max Reverse Voltage (DC) :
- 60V
- Number of Functions :
- 1
- Length :
- 5mm
- Width :
- 4.24mm
- Reverse Breakdown Voltage :
- 60V
- HTS Code :
- 8541.40.60.50
- Infrared Range :
- yes
- Operating Temperature :
- -40°C~100°C
- Max Power Dissipation :
- 215mW
- Rise Time :
- 100ns
- Pbfree Code :
- yes
- REACH SVHC :
- Unknown
- Factory Lead Time :
- 7 Weeks
- Shape :
- RECTANGULAR
- Mount :
- PCB, Surface Mount
- Mounting Type :
- Surface Mount
- Spectral Range :
- 430nm ~ 1100nm
- RoHS Status :
- ROHS3 Compliant
- Terminal Finish :
- Matte Tin (Sn)
- Radiation Hardening :
- No
- Lead Free :
- Lead Free
- Size :
- 4.4mm
- Moisture Sensitivity Level (MSL) :
- 4 (72 Hours)
- Additional Feature :
- HIGH SENSITIVITY
- Published :
- 2009
- Packaging :
- Tape and Reel (TR)
- Semiconductor Material :
- SILICON
- Wavelength :
- 900nm
- Number of Pins :
- 2
- Light Current-Nom :
- 0.035mA
- Reverse Voltage (DC) :
- 60V
- Power Dissipation :
- 215mW
- Forward Voltage :
- 1.3V
- Dark Current :
- 2nA
- Forward Current :
- 50mA
- Package / Case :
- 4-SMD, No Lead
- Active Area :
- 4.4mm2
- Datasheets
- TEMD5020X01
TEMD5020X01 Documents
Surface Mount -40°C~100°C Tape & Reel (TR) Wavelength: 900nm 4-SMD, No Lead 4.4mm2 2nA
TEMD5020X01 Overview
Tape & Reel (TR) is used to protect the photodiodes from damage. A safety package containing the photodiodes is provided for their protection. When the photodiodes are reverse-biased, the voltage should never exceed 60V. A photodiode has a pin number of 2. There was the possibility that photodiodes in a circuit would emit 215mW heat. The reverse anode voltage for the photodiodes should be 60V. In general, the maximum heat generated by photodiodes should be 215mW in a circuit. With the reverse voltage of 60V, the photodiodes in the DC circuit can work properly. In order for a photodiode to pass current, you need a voltage of 1.3V. The current in a photodiode is 2nA even when there is no light input.
TEMD5020X01 Features
Moisture Sensitivity Level (MSL): 4 (72 Hours)
Operating Temperature: -40°C~100°C
Packaging: Tape & Reel (TR)
Diode Type: PIN
Mount: PCB, Surface Mount
Spectral Range: 430nm ~ 1100nm
Viewing Angle: 130°
TEMD5020X01 Applications
There are a lot of Vishay Semiconductor Opto Division
TEMD5020X01 Photodiodes applications.
- Shaft encoders
- Electronic Equipment
- Industrial Automation
- Machine Controls
- Light Barriers
- Vision Controls
- Measurement Levelling
- High speed photo detectors
- Health Monitoring
- Heart Rate Monitoring
