FDMA008P20LZ

Manufacturer :

onsemi

Product Category :

Transistors - FETs, MOSFETs - Single

Reach Compliance Code :

not_compliant

Vgs(th) (Max) @ Id :

1.4V @ 250μA

Package / Case :

6-PowerWDFN

Gate Charge (Qg) (Max) @ Vgs :

39nC @ 4.5V

Mounting Type :

Surface Mount

Lifecycle Status :

ACTIVE (Last Updated: 3 days ago)

Terminal Finish :

Tin (Sn)

Packaging :

Tape and Reel (TR)

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Factory Lead Time :

10 Weeks

Rds On (Max) @ Id, Vgs :

13m Ω @ 2.5A, 4.5V

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Pbfree Code :

yes

JESD-609 Code :

e3

RoHS Status :

ROHS3 Compliant

Power Dissipation-Max :

2.4W Ta

Drain to Source Voltage (Vdss) :

20V

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Operating Temperature :

-55°C~150°C TJ

Element Configuration :

Single

FET Type :

P-Channel

Vgs (Max) :

±8V

Mount :

Surface Mount

Input Capacitance (Ciss) (Max) @ Vds :

4383pF @ 10V

Current - Continuous Drain (Id) @ 25°C :

12A Ta

Drive Voltage (Max Rds On,Min Rds On) :

1.5V 4.5V

Weight :

21.13402mg
