BC337-40BK

Manufacturer :

Diotec Semiconductor

Product Category :

Transistors - Bipolar (BJT) - Single

Package :

Retail Package

Manufacturer :

Diotec Semiconductor AG

Output Power :

Not Required(W)

Terminal Position :

BOTTOM

HTS Code :

8541.21.00.95

Packaging :

Box

Surface Mount :

No

Category :

Bipolar Small Signal

Series :

*

Pin Count :

3

Mounting :

Through Hole

Peak Reflow Temperature (Cel) :

NOT SPECIFIED

Frequency :

100(MHz)

Qualification Status :

Not Qualified

JEDEC-95 Code :

TO-92

Operating Temp Range :

-55C to 150C

JESD-30 Code :

O-PBCY-W3

Configuration :

Single

Product Status :

Active

Polarity/Channel Type :

NPN

Collector Current-Max (IC) :

0.8 A

Number of Elements :

1

Collector-Emitter Voltage :

45(V)

Collector Current (DC) :

0.8(A)

Reach Compliance Code :

Compliant

Number of Terminals :

3

Collector-Emitter Voltage-Max :

45 V

Transistor Polarity :

NPN

Rad Hardened :

No

Terminal Form :

Wire

Operating Temperature Classification :

Military

ECCN Code :

EAR99

DC Current Gain :

250

Package Shape :

Round

Package Type :

TO-92

Emitter-Base Voltage :

5(V)

Transistor Element Material :

SILICON

Power Dissipation :

0.625(W)

DC Current Gain-Min (hFE) :

170
