IPBD-08-D

Manufacturer :

Samtec, Inc.

Product Category :

Rectangular Connector Housings

Pbfree Code :

yes

Gender :

FEMALE

Mating Information :

MULTIPLE MATING PARTS AVAILABLE

Body Breadth :

0.478 inch

HTS Code :

8536.69.40.30

Shell Material :

VALOX 457

DIN Conformance :

No

Connector Type :

Receptacle

JESD-609 Code :

e3

Factory Lead Time :

1 Weeks

Row Spacing :

0.165 (4.20mm)

Reliability :

COMMERCIAL

Orientation :

Straight

Body/Shell Style :

PLUG

Mounting Option 2 :

LOCKING

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Length :

34.54mm

Contact Type :

Female Socket

Number of Positions :

16

ECCN Code :

EAR99

Filter Feature :

No

Number of Rows :

2

Max Operating Temperature :

105°C

Empty Shell :

No

Wire Gauge (Max) :

24 AWG

Wire Gauge (Min) :

16 AWG

Number of Conductors :

ONE

Mixed Contacts :

No

Mounting Option 1 :

POLARIZED LCK

MIL Conformance :

No

Additional Feature :

SHROUDED

Max Voltage Rating (AC) :

600V

Contact Termination :

Crimp

Mounting Type :

Free Hanging (In-Line)

Series :

Power Mate® IPBD

Min Operating Temperature :

-40°C

Note :

Contacts Not Included

Total Number of Contacts :

16

Radiation Hardening :

No

Fastening Type :

Latch Lock

Contact Finish - Mating :

TIN OVER NICKEL (50)

Published :

2013

Depth :

19.56mm

Option :

GENERAL PURPOSE

Pitch :

0.165 4.20mm

RoHS Status :

ROHS3 Compliant

IEC Conformance :

No

Reference Standard :

UL

Packaging :

Bulk
