UUG2A680MNQ1MS

Share

Or copy the link below:

Mfr.Part #
UUG2A680MNQ1MS
Manufacturer
Nichicon
Package / Case
Radial, Can - SMD
Datasheet
Download
Description
CAP ALUM 68UF 20% 100V SMD
Stock
300
In Stock :
300

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
Nichicon
Product Category :
Aluminum Electrolytic Capacitors
Life (Hours) :
2000 hours
Package / Case :
Radial, Can - SMD
Size / Dimension :
0.492Dia 12.50mm
Applications :
GENERAL PURPOSE
HTS Code :
8532.22.00
RoHS Status :
ROHS3 Compliant
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Terminal Finish :
Matte Tin (Sn)
Published :
2009
Polarization :
Polar
Lead Free :
Lead Free
Series :
UUG
Length :
14.6mm
Lifetime @ Temp :
2000 Hrs @ 85°C
Surface Mount Land Size :
0.535Lx0.535W 13.60mmx13.60mm
Height :
13.5mm
Size Code :
5454
Dielectric Material :
ALUMINUM (WET)
Number of Terminations :
2
Ripple Current @ Low Frequency :
350mA @ 120Hz
Mount :
Surface Mount
Pbfree Code :
yes
Operating Temperature :
-40°C~85°C
JESD-609 Code :
e3
Terminal Shape :
Flat
Voltage - Rated DC :
100V
Factory Lead Time :
24 Weeks
Mounting Type :
Surface Mount
Height Seated (Max) :
0.571 14.50mm
Packaging :
Tape and Reel (TR)
Ripple Current :
350mA
Width :
13.6mm
ECCN Code :
EAR99
Capacitance :
68µF
Leakage Current :
100μA
Capacitor Type :
ALUMINUM ELECTROLYTIC CAPACITOR
Dissipation Factor :
0.08 %
Termination :
SMD/SMT
Tolerance :
±20%
Introducing Aluminum Electrolytic Capacitors Nichicon UUG2A680MNQ1MS from Chip IC,where excellence meets affordability. This product stands out with its Package / Case:Radial, Can - SMD, Number of Terminations:2, Operating Temperature:-40°C~85°C, Mounting Type:Surface Mount, UUG2A680MNQ1MS pinout, UUG2A680MNQ1MS datasheet PDF, UUG2A680MNQ1MS amp .Beyond Aluminum Electrolytic Capacitors Nichicon UUG2A680MNQ1MS ,we also offer 865080642006, 865080342006, EEE-FK1E100R, Our vast inventory has you covered. Contact us now for immediate solutions.

Nichicon UUG2A680MNQ1MS


UUG 68μF Capacitor ±20% Tape & Reel (TR) Surface Mount 350mA 0.492Dia 12.50mm -40°C~85°C Polar Radial, Can - SMD
