PMP4201G135
- Mfr.Part #
- PMP4201G135
- Manufacturer
- NXP Semiconductors
- Package / Case
- 5-TSSOP, SC-70-5, SOT-353
- Datasheet
- Download
- Description
- SMALL SIGNAL BIPOLAR TRANSISTOR
- Stock
- 5,180
- In Stock :
- 5,180
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- NXP Semiconductors
- Product Category :
- Transistors - Bipolar (BJT) - Arrays
- Max Power Dissipation :
- 300mW
- Terminal Form :
- Gull wing
- Collector Emitter Voltage (VCEO) :
- 45V
- Number of Pins :
- 5
- Max Breakdown Voltage :
- 45V
- Transition Frequency :
- 250MHz
- RoHS Status :
- RoHS Compliant
- ECCN Code :
- EAR99
- Terminal Finish :
- Tin (Sn)
- Published :
- 2009
- Mount :
- Surface Mount
- Radiation Hardening :
- No
- Operating Temperature :
- 150°C TJ
- Time@Peak Reflow Temperature-Max (s) :
- 40
- Transistor Type :
- 2 NPN (Dual) Matched Pair, Common Emitter
- Current - Collector Cutoff (Max) :
- 15nA ICBO
- Collector Base Voltage (VCBO) :
- 50V
- Packaging :
- Tape and Reel (TR)
- Collector Emitter Breakdown Voltage :
- 45V
- Max Collector Current :
- 100mA
- Case Connection :
- Isolated
- Number of Terminations :
- 5
- Peak Reflow Temperature (Cel) :
- 260
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Base Part Number :
- PMP4201
- Pin Count :
- 5
- Element Configuration :
- Dual
- Power - Max :
- 300mW
- Transistor Application :
- AMPLIFIER
- Number of Elements :
- 2
- JESD-609 Code :
- e3
- Factory Lead Time :
- 6 Weeks
- Vce Saturation (Max) @ Ib, Ic :
- 400mV @ 5mA, 100mA
- DC Current Gain (hFE) (Min) @ Ic, Vce :
- 200 @ 2mA 5V
- Gain Bandwidth Product :
- 250MHz
- Mounting Type :
- Surface Mount
- Emitter Base Voltage (VEBO) :
- 6V
- Polarity :
- NPN
- Transistor Element Material :
- SILICON
- Package / Case :
- 5-TSSOP, SC-70-5, SOT-353
