M83513/01-BN

Share

Or copy the link below:

Mfr.Part #
M83513/01-BN
Manufacturer
Cinch Connectivity Solutions
Package / Case
SOD
Datasheet
Download
Description
15 POS PLUG SOLDER CUP NI PLTD
Stock
97
In Stock :
97

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
Cinch Connectivity Solutions
Product Category :
D-Sub Connector Assemblies
Connector Type :
D MICROMINIATURE CONNECTOR
Voltage Rating :
-
Shell Material, Finish :
Aluminum, Nickel Plated, Electroless
Subcategory :
MIL-Spec / MIL-Type
Product :
Connectors
Current Rating :
3A
Dielectric Withstanding Voltage :
600VAC V
Wire Gauge :
-
Number of Conductors :
ONE
Connector Style :
D-Type, Micro-D
Mounting Type :
Free Hanging (In-Line)
Body Breadth :
0.384 inch
Shell Size :
B
Color :
-
Empty Shell :
No
Contact Gender :
Male
Number of Terminations :
15
Mixed Contacts :
No
Mounting Style :
Panel
Flange Feature :
Housing/Shell (Unthreaded)
Plating Thickness :
50μin
RoHS :
Details
Body/Shell Style :
PLUG
Termination Style :
Solder Cup
Shell Finish :
Nickel
Shell Size, Connector Layout :
0.050 Pitch x 0.043 Row to Row
Manufacturer :
ITT Cannon
Contact Material :
COPPER ALLOY
Pitch :
1.27mm
Series :
M83513
Dielectric Material :
Liquid Crystal Polymer (LCP)
Depth :
15.65mm
MIL Conformance :
yes
Insulation Resistance :
5000000000Ohm
Backset Spacing :
-
Orientation :
Straight
Filter Feature :
No
Ingress Protection :
-
Contact Resistance :
8mOhm
Length :
23.75mm
Material Flammability Rating :
-
Contact Type :
Signal
DIN Conformance :
No
Mount :
Panel
Durability :
500 Cycles
IEC Conformance :
No
RoHS Status :
RoHS Compliant
Shell Material :
Metal
Number of Rows :
2
Operating Temperature :
-55°C ~ 125°C
Contact Style :
RND PIN-SKT
Contact Plating :
Gold
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Product Status :
Active
Number of Positions :
15 Position
Operating Temperature (Min) :
-55°C
Package / Case :
SOD
HTS Code :
8536.69.40.30
Mounting Angle :
Straight
Contact Pattern :
STAGGERED
Option :
GENERAL PURPOSE
Mating Information :
MULTIPLE MATING PARTS AVAILABLE
Termination :
Solder
Mating Contact Row Spacing :
0.043 inch
Current Rating (Amps) :
3A
Contact Finish Thickness :
50.0µin (1.27µm)
Total Number of Contacts :
15
Package :
Bulk
Rated Current (Signal) :
3A
Reference Standard :
MIL
Features :
-
Radiation Hardening :
No
Published :
2002
Product Category :
D-Sub MIL Spec Connectors
ECCN Code :
EAR99
Contact Form :
-
Gender :
Male
Product Type :
D-Sub MIL Spec Connectors
Contact Finish :
Gold
Tradename :
MIL-DTL-83513
Brand :
ITT Cannon
Number of Ports :
1
Housing Material :
Polymer
Introducing D-Sub Connector Assemblies Cinch Connectivity Solutions M83513/01-BN from Chip IC,where excellence meets affordability. This product stands out with its Mounting Type:Free Hanging (In-Line), Number of Terminations:15, Operating Temperature:-55°C ~ 125°C, Package / Case:SOD, M83513/01-BN pinout, M83513/01-BN datasheet PDF, M83513/01-BN amp .Beyond D-Sub Connector Assemblies Cinch Connectivity Solutions M83513/01-BN ,we also offer ICD15S13E4GX00LF, L77SDEH09SOL2RM5, A-DF 25 A/KG-T2S, Our vast inventory has you covered. Contact us now for immediate solutions.

Cinch Connectivity Solutions M83513/01-BN


M83513 Series D-Type, Micro-D D MICROMINIATURE CONNECTOR 15 Position-Position Male Signal Solder 0.050 Pitch x 0.043 Row to Row Free Hanging (In-Line) Copper Alloy Gold Aluminum, Nickel Plated, Electroless

M83513/01-BN Overview


A D MICROMINIATURE CONNECTOR package is included with it.Free Hanging (In-Line) indicates that the device is mounted.The product is a part of the M83513 Series.SOD refers to a package enclosing a device.With 1 ports, it is capable of managing a wide range of tasks.By Panel, the part is mounted.In this chip, the terminations are all 15.Operating temperature is set to -55°C ~ 125°C.
