M83513/01-BN

Share

Or copy the link below:

Mfr.Part #
M83513/01-BN
Manufacturer
Cinch Connectivity Solutions
Package / Case
SOD
Datasheet
Download
Description
CINCH 15C PIN SOLDER NI
Stock
14,133
In Stock :
14,133

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
Cinch Connectivity Solutions
Product Category :
D-Sub Connector Assemblies
Shell Size, Connector Layout :
0.050 Pitch x 0.043 Row to Row
Product Status :
Active
Radiation Hardening :
No
Total Number of Contacts :
15
Contact Resistance :
8mOhm
Package / Case :
SOD
Connector Style :
D-Type, Micro-D
Reference Standard :
MIL
Dielectric Material :
Liquid Crystal Polymer (LCP)
Flange Feature :
Housing/Shell (Unthreaded)
HTS Code :
8536.69.40.30
Shell Finish :
Nickel
Shell Material, Finish :
Aluminum, Nickel Plated, Electroless
Mixed Contacts :
No
Filter Feature :
No
Current Rating (Amps) :
3A
Wire Gauge :
-
Mount :
Panel
Number of Ports :
1
ECCN Code :
EAR99
Gender :
Male
IEC Conformance :
No
Features :
-
Number of Positions :
15 Position
Contact Gender :
Male
Connector Type :
D MICROMINIATURE CONNECTOR
Ingress Protection :
-
Contact Plating :
Gold
Current Rating :
3A
Length :
23.75mm
Termination Style :
Solder Cup
Insulation Resistance :
5000000000Ohm
Mounting Type :
Free Hanging (In-Line)
Backset Spacing :
-
DIN Conformance :
No
Body/Shell Style :
PLUG
Product Type :
D-Sub MIL Spec Connectors
Manufacturer :
ITT Cannon
Rated Current (Signal) :
3A
Published :
2002
Housing Material :
Polymer
Orientation :
Straight
MIL Conformance :
yes
Product :
Connectors
Number of Rows :
2
Depth :
15.65mm
Product Category :
D-Sub MIL Spec Connectors
Voltage Rating :
-
Shell Material :
Metal
Durability :
500 Cycles
Empty Shell :
No
Subcategory :
MIL-Spec / MIL-Type
Number of Conductors :
ONE
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Termination :
Solder
Plating Thickness :
50μin
RoHS Status :
RoHS Compliant
Option :
GENERAL PURPOSE
Dielectric Withstanding Voltage :
600VAC V
Operating Temperature :
-55°C ~ 125°C
Number of Terminations :
15
Contact Finish :
Gold
Color :
-
Contact Material :
COPPER ALLOY
Tradename :
MIL-DTL-83513
Mounting Angle :
Straight
Body Breadth :
0.384 inch
Package :
Bulk
Contact Style :
RND PIN-SKT
Series :
M83513
Material Flammability Rating :
-
Mating Information :
MULTIPLE MATING PARTS AVAILABLE
RoHS :
Details
Mating Contact Row Spacing :
0.043 inch
Brand :
ITT Cannon
Contact Form :
-
Contact Finish Thickness :
50.0µin (1.27µm)
Operating Temperature (Min) :
-55°C
Shell Size :
B
Contact Pattern :
STAGGERED
Mounting Style :
Panel
Pitch :
1.27mm
Contact Type :
Signal
Introducing D-Sub Connector Assemblies Cinch Connectivity Solutions M83513/01-BN from Chip IC,where excellence meets affordability. This product stands out with its Package / Case:SOD, Mounting Type:Free Hanging (In-Line), Operating Temperature:-55°C ~ 125°C, Number of Terminations:15, M83513/01-BN pinout, M83513/01-BN datasheet PDF, M83513/01-BN amp .Beyond D-Sub Connector Assemblies Cinch Connectivity Solutions M83513/01-BN ,we also offer ICD15S13E4GX00LF, L77SDEH09SOL2RM5, A-DF 25 A/KG-T2S, Our vast inventory has you covered. Contact us now for immediate solutions.

Cinch Connectivity Solutions M83513/01-BN


M83513 Series D-Type, Micro-D D MICROMINIATURE CONNECTOR 15 Position-Position Male Signal Solder 0.050 Pitch x 0.043 Row to Row Free Hanging (In-Line) Copper Alloy Gold Aluminum, Nickel Plated, Electroless

M83513/01-BN Overview


A D MICROMINIATURE CONNECTOR package is included with it.Free Hanging (In-Line) indicates that the device is mounted.The product is a part of the M83513 Series.SOD refers to a package enclosing a device.With 1 ports, it is capable of managing a wide range of tasks.By Panel, the part is mounted.In this chip, the terminations are all 15.Operating temperature is set to -55°C ~ 125°C.

M83513/01-BN Features


15 basic kinds of terminations
M83513 series


M83513/01-BN Applications


There are a lot of ITT Cannon, LLC
M83513/01-BN D-Sub Connectors applications.


  • Communication
  • Medical technology
  • Military Technology
  • Measuring & Control Technology
  • Instrumentation
  • Automotive Electronics
  • Telecommunications
  • Data Technology
  • Blowers
  • Control panels
Purchase

You may place an order without registering to Chip IC. We strongly recommend that you log in before purchasing as you can track your order at any time.

RFQ (Request for Quotations)

It is recommended to send RFQ to get the latest prices and stock availability about the part.Our sales will reply to your inquiry within 24 hours.

Payment Method

For your convenience, we accept multiple payment methods in USD, Such as:PayPal, Credit Card, and wire transfer.

IMPORTANT NOTICE

You may place an order without registering to 1. You'll receive an order confirmations by e-mail soon . (Please remember to check the spam box if you didn't hear from us). 2. Since stock availability and prices may change at any time, the sales will reconfirm the order details and update you at soonest time.

Shipping Method

Most of our products are shipped via FEDEX,DHL,UPS and SF EXPRESS...

Shipping Cost

Shipping Cost starts at $40, but some countries will exceed $40. For example (South Africa, Brazil, India, Pakistan, Israel, etc.).If customer have shipping account, we can make shipment under customer’s shipping account with freight collect directly.

The basic freight (for package ≤0.5 KG ) depends on the time zones and countries

Delivery Time

Once the goods are shipped, estimated delivery time depends on the shipping methods you chose. You can track it by the tracking no.
