LGR2G221MELB40

Manufacturer :

Nichicon

Product Category :

Aluminum Electrolytic Capacitors

Dielectric Material :

ALUMINUM (WET)

RoHS Status :

ROHS3 Compliant

Number of Pins :

2

Factory Lead Time :

19 Weeks

Voltage - Rated DC :

400V

Lifetime @ Temp :

10000 Hrs @ 105°C

Terminal Finish :

Matte Tin (Sn)

Mounting Type :

Through Hole

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Capacitor Type :

ALUMINUM ELECTROLYTIC CAPACITOR

Tolerance :

±20%

Capacitance :

220μF

Terminal Pitch :

10mm

JESD-609 Code :

e3

Ripple Current @ High Frequency :

1.43A @ 50kHz

Dissipation Factor :

0.15 %

Termination :

Snap in

Mount :

Through Hole

Leakage Current :

880μA

Published :

2009

Series :

LGR

Ripple Current :

1A

Polarization :

Polar

Life (Hours) :

10000 hours

Number of Terminations :

2

Packaging :

Bulk

Applications :

GENERAL PURPOSE

Lead Spacing :

0.394 10.00mm

Package / Case :

Radial, Can - Snap-In

Test Frequency :

120Hz

Operating Temperature :

-25°C~105°C

Ripple Current @ Low Frequency :

1A @ 120Hz

Length :

40mm

Diameter :

30mm

Height Seated (Max) :

1.654 42.00mm

Pbfree Code :

yes

ECCN Code :

EAR99

Lead Pitch :

10.0076mm

Size / Dimension :

1.181Dia 30.00mm
