IXGN320N60A3

Share

Or copy the link below:

Mfr.Part #
IXGN320N60A3
Manufacturer
Littelfuse
Package / Case
SOT-227-4, miniBLOC
Datasheet
Download
Description
IGBT MOD 600V 320A 735W SOT227B
Stock
1,912
In Stock :
1,912

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
Littelfuse
Product Category :
Transistors - IGBTs - Modules
Additional Feature :
LOW CONDUCTION LOSS, UL RECOGNIZED
Weight :
38.000013g
Input Capacitance :
18nF
Series :
GenX3™
Width :
25.42 mm
Input :
Standard
NTC Thermistor :
No
Manufacturer :
IXYS
Current - Collector (Ic) (Max) :
320A
Supplier Device Package :
SOT-227B
Number of Pins :
4
Package :
Tube
Factory Lead Time :
30 Weeks
Vce(on) (Max) @ Vge, Ic :
1.25V @ 15V, 100A
Channel Type :
N
Terminal Position :
UPPER
Gate-Emitter Voltage-Max :
20V
Collector Emitter Voltage (VCEO) :
600V
Operating Temperature :
-55°C~150°C TJ
Pbfree Code :
yes
RoHS Status :
ROHS3 Compliant
Terminal Form :
UNSPECIFIED
Voltage - Collector Emitter Breakdown (Max) :
600V
Technology :
Si
Reach Compliance Code :
Unknown
Length :
38.23 mm
Input Capacitance (Cies) @ Vce :
18nF @ 25V
Base Product Number :
IXGN320
Brand :
IXYS
Package Type :
SOT-227B
Published :
2009
Height :
9.6 mm
Collector Emitter Breakdown Voltage :
600V
Product Type :
IGBT Transistors
Terminal Finish :
Nickel
Configuration :
Single
Transistor Application :
POWER CONTROL
Turn On Delay Time :
63 ns
Mounting Type :
Chassis Mount
Mounting Style :
Screw Mounts
Max Power Dissipation :
735W
Dimensions :
38.23 x 25.07 x 9.6mm
VCEsat-Max :
1.25 V
Lead Free :
Lead Free
Polarity/Channel Type :
N-Channel
Product Status :
Active
Minimum Operating Temperature :
-55 °C
Number of Elements :
1
Power - Max :
735W
Mount :
Chassis Mount, Screw
IGBT Type :
PT
Package / Case :
SOT-227-4, miniBLOC
Turn Off Time-Nom (toff) :
1870 ns
Case Connection :
Isolated
Current - Collector Cutoff (Max) :
150μA
Switching Speed :
5kHz
Packaging :
Tube
Product Category :
IGBT Transistors
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Pin Count :
4
RoHS :
Details
Transistor Element Material :
SILICON
Max Collector Current :
320A
Turn-Off Delay Time :
290 ns
Turn On Time :
139 ns
Maximum Operating Temperature :
+150 °C
Number of Terminations :
4
Introducing Transistors - IGBTs - Modules Littelfuse IXGN320N60A3 from Chip IC,where excellence meets affordability. This product stands out with its Number of Pins:4, Operating Temperature:-55°C~150°C TJ, Mounting Type:Chassis Mount, Package / Case:SOT-227-4, miniBLOC, Number of Terminations:4, IXGN320N60A3 pinout, IXGN320N60A3 datasheet PDF, IXGN320N60A3 amp .Beyond Transistors - IGBTs - Modules Littelfuse IXGN320N60A3 ,we also offer FS450R12KE3BOSA1, VS-GT80DA120U, FD450R12KE4PHOSA1, Our vast inventory has you covered. Contact us now for immediate solutions.
