DRQ127-R47-R
Or copy the link below:
- Mfr.Part #
- DRQ127-R47-R
- Manufacturer
- Eaton-Electronics Division
- Package / Case
- Nonstandard
- Datasheet
- Download
- Description
- INDUCT ARRAY 2 COIL 419NH SMD
- Stock
- 600
- In Stock ：
- 600
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Eaton-Electronics Division
- Product Category :
- Arrays, Signal Transformers
- Min Operating Temperature :
- -40°C
- Mounting Type :
- Surface Mount
- Core Material :
- Ferrite
- Max Operating Temperature :
- 125°C
- Size / Dimension :
- 0.492Lx0.492W 12.50mmx12.50mm
- Resistance :
- 1.95mOhm
- Packaging :
- Tape and Reel (TR)
- Current :
- 8.94A
- Termination :
- SMD/SMT
- Shielding :
- Shielded
- Factory Lead Time :
- 14 Weeks
- Published :
- 2014
- DC Resistance (DCR) - Series :
- 7.8mOhm
- Inductance - Parallel :
- 419 nH
- Operating Temperature :
- -40°C~125°C
- Current Rating - Series :
- 8.94A
- Height :
- 0.315 8.00mm
- Weight :
- 5.443108g
- RoHS Status :
- ROHS3 Compliant
- Series :
- DRQ
- DC Resistance (DCR) - Parallel :
- 1.95mOhm
- Inductance - Connected In Series :
- 1.676μH
- Inductance :
- 470 nH
- Inductance - Series :
- 1.676 µH
- Mount :
- Surface Mount
- Number of Coils :
- 2
- Inductance - Connected In Parallel :
- 419nH
- Current Saturation - Parallel :
- 56A
- Lead Free :
- Lead Free
- Current Rating - Parallel :
- 17.9A
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Max DC Current :
- 56A
- Length :
- 12.4968mm
- Number of Pins :
- 4
- Width :
- 12.4968mm
- Current Saturation - Series :
- 28A
- Tolerance :
- ±20%
- Package / Case :
- Nonstandard
- Datasheets
- DRQ127-R47-R
DRQ127-R47-R datasheet pdf and Arrays, Signal Transformers product details from Eaton - Electronics Division stock available at
