Mfr.Part #
APTGF100A120T3AG
Manufacturer
Microsemi
Package / Case
SP3
Datasheet
Download
Description
IGBT MODULE 1200V 130A 780W SP3
Stock
43,186
In Stock :
43,186

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
Microsemi
Product Category :
Transistors - IGBTs - Modules
Max Collector Current :
130A
Max Power Dissipation :
780W
Peak Reflow Temperature (Cel) :
NOT SPECIFIED
Input Capacitance :
6.5nF
Turn On Time :
190 ns
NTC Thermistor :
yes
Configuration :
Half Bridge
Terminal Form :
UNSPECIFIED
RoHS Status :
RoHS Compliant
Collector Emitter Breakdown Voltage :
1.2kV
Min Operating Temperature :
-40°C
Number of Pins :
20
Terminal Position :
UPPER
Polarity/Channel Type :
N-Channel
Case Connection :
Isolated
Voltage - Collector Emitter Breakdown (Max) :
1200V
JESD-30 Code :
R-XUFM-X10
VCEsat-Max :
3.7 V
Time@Peak Reflow Temperature-Max (s) :
NOT SPECIFIED
Pin Count :
25
Element Configuration :
Dual
Vce(on) (Max) @ Vge, Ic :
3.7V @ 15V, 100A
Current - Collector Cutoff (Max) :
250μA
Max Operating Temperature :
150°C
IGBT Type :
NPT
Number of Terminations :
10
Input :
Standard
ECCN Code :
EAR99
Package / Case :
SP3
Input Capacitance (Cies) @ Vce :
6.5nF @ 25V
Number of Elements :
2
Mount :
Chassis Mount, Screw
Mounting Type :
Chassis Mount
Collector Emitter Voltage (VCEO) :
1.2kV
Transistor Application :
POWER CONTROL
Qualification Status :
Not Qualified
Turn Off Time-Nom (toff) :
390 ns
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Introducing Transistors - IGBTs - Modules Microsemi APTGF100A120T3AG from Chip IC,where excellence meets affordability. This product stands out with its Number of Pins:20, Number of Terminations:10, Package / Case:SP3, Mounting Type:Chassis Mount, APTGF100A120T3AG pinout, APTGF100A120T3AG datasheet PDF, APTGF100A120T3AG amp .Beyond Transistors - IGBTs - Modules Microsemi APTGF100A120T3AG ,we also offer FS450R12KE3BOSA1, VS-GT80DA120U, FD450R12KE4PHOSA1, Our vast inventory has you covered. Contact us now for immediate solutions.

Microsemi APTGF100A120T3AG
