Mfr.Part #
5650090-7
Manufacturer
TE Connectivity AMP Connectors
Package / Case
Datasheet
Download
Description
CONN EDGE DUAL FMALE 46POS 0.050
Stock
1,007
In Stock :
1,007

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
TE Connectivity AMP Connectors
Product Category :
Edgeboard Connectors
Lifecycle Status :
ACTIVE (Last Updated: 4 days ago)
Contact Finish :
Gold
Pitch :
0.050 1.27mm
Color :
Brown
Dielectric Withstanding Voltage :
500VAC V
IEC Conformance :
No
Number of Rows :
2
Factory Lead Time :
23 Weeks
JESD-609 Code :
e3
Option :
GENERAL PURPOSE
Contact Resistance :
30mOhm
Rated Current (Signal) :
1A
Contact Style :
BELLOWED TYPE
Number of Positions/Bay/Row :
11; 12
Orientation :
Vertical
Filter Feature :
No
Body Breadth :
0.35 inch
Termination :
Solder, Staggered
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Series :
Standard Edge .050
Operating Supply Voltage :
203V
Mixed Contacts :
No
Board Thickness :
1.57mm
Contact Finish Thickness :
30.0μin 0.76μm
Circuit Application :
Signal
Gender :
FEMALE
Mounting Type :
Through Hole
Additional Feature :
POLARIZED
Material - Insulation :
Thermoplastic
Published :
2007
Card Thickness :
0.062 1.57mm
Length - Termination :
0.1 inch
Radiation Hardening :
No
Body Depth :
0.61 inch
Durability :
100 Cycles
Contact Pattern :
RECTANGULAR
Reference Standard :
CSA
Read Out :
Dual
Number of Positions :
46
Operating Temperature :
-55°C~85°C
Insulation Resistance :
1000000000Ohm
MIL Conformance :
No
Number Of PCB Rows :
4
Max Voltage Rating (AC) :
203V
Contact Current Rating :
1A
DIN Conformance :
No
Lead Length :
2.54mm
Mount :
Through Hole
Connector Type :
Connector, Receptacle, Socket
Height :
13.97mm
Contact Material :
Phosphor Bronze
Reliability :
COMMERCIAL
Plating Thickness :
760 nm
Total Number of Contacts :
46
Current Rating :
1A
Contact Plating :
Gold, Tin
RoHS Status :
RoHS Compliant
Underplate Material :
Nickel
Packaging :
Bulk
Card Type :
Non Specified - Dual Edge
Number of Conductors :
ONE
Body Length or Diameter :
1.49 inch
Feature :
Board Guide
