5-487508-7

Manufacturer :

TE Connectivity AMP Connectors

Product Category :

FFC, FPC (Flat Flexible) Connector Assemblies

Wire/Cable Type :

Straight

Connector Type :

Connector, Receptacle, Socket

Packaging :

Bulk

Voltage - Rated :

250V

Mating Connector Lock :

Without

Sealable :

No

Mating Cycles :

25

ELV :

Compliant

Current Rating :

1A

Reliability :

COMMERCIAL

Material Flammability Rating :

UL94 V-0

Gender :

FEMALE

Mating Alignment :

With

Lifecycle Status :

ACTIVE (Last Updated: 5 months ago)

Insulation Resistance :

5000000000Ohm

Contact Finish Thickness :

196.9μin 5.00μm

Orientation :

RIGHT ANGLE

RoHS Status :

RoHS Compliant

Operating Temperature :

-55°C~105°C

Flammability Rating :

UL94 V-0

Mount :

Through Hole

Total Number of Contacts :

8

Contact Material :

Phosphor Bronze

Flat Flex Type :

FFC, FPC

Plating Thickness :

5µm

Series :

Triomate

Contact Style :

LEAF

Contact Finish :

Tin

Reference Standard :

UL

Depth :

6.93mm

Number of Rows :

1

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Mounting Type :

Through Hole, Right Angle

Pitch :

0.100 2.54mm

Published :

2009

Termination :

Kinked Pin

PCB Mounting Orientation :

RIGHT ANGLE

Housing Material :

Polyester Thermoplastic, Glass Filled

Contact Pattern :

RECTANGULAR

Length :

25.22mm

Number of Positions :

8

Height Above Board :

0.190 4.83mm

Lead Length :

4.064mm

PCB Thickness :

1.57mm

FFC, FCB Thickness :

0.13mm ~ 0.38mm

Housing Color :

Black

PCB Contact Pattern :

RECTANGULAR

Circuit Application :

Signal

Connector/Contact Type :

Contacts, Top

Factory Lead Time :

18 Weeks

Length - Tail :

80.772mm

Rated Current (Signal) :

1A

Number Of PCB Rows :

1
