M48T12-150PC1
Or copy the link below:
- Mfr.Part #
- M48T12-150PC1
- Manufacturer
- STMicroelectronics
- Package / Case
- 24-DIP Module (0.600, 15.24mm)
- Datasheet
- Download
- Description
- IC RTC CLK/CALENDAR PAR 24DIP
- Stock
- 939
- In Stock ：
- 939
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- STMicroelectronics
- Product Category :
- Real Time Clocks
- Package / Case :
- 24-DIP Module (0.600, 15.24mm)
- Factory Lead Time :
- 25 Weeks
- Lead Free :
- Lead Free
- Access Time :
- 150 ns
- Lifecycle Status :
- ACTIVE (Last Updated: 6 months ago)
- Interface :
- Parallel
- ECCN Code :
- EAR99
- Frequency :
- 150GHz
- Number of Pins :
- 24
- Mounting Type :
- Through Hole
- JESD-609 Code :
- e3
- Voltage - Supply :
- 4.5V~5.5V
- Number of Terminations :
- 24
- Series :
- Timekeeper®
- Pin Count :
- 24
- Radiation Hardening :
- No
- Power Supplies :
- 5V
- Terminal Pitch :
- 2.54mm
- Operating Supply Voltage :
- 5V
- Mount :
- Through Hole
- Terminal Finish :
- Matte Tin (Sn)
- Height :
- 8.89mm
- Additional Feature :
- 10 YEARS DATA RETENTION; ACCURACY 1 MIN/MONTH @ 25 DEGREE C; WRITE PROTECT VOLTAGE = 4.2V
- Supply Voltage :
- 5V
- Time-Min :
- SECONDS
- Interrupt Capability :
- N
- Logic Function :
- Clock
- Nominal Supply Current :
- 80mA
- Feature :
- Leap Year
- Operating Temperature :
- 0°C~70°C
- Type :
- Clock/Calendar
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Memory Size :
- 2kB
- RoHS Status :
- ROHS3 Compliant
- HTS Code :
- 8542.39.00.01
- Base Part Number :
- M48T12
- Length :
- 34.8mm
- REACH SVHC :
- No SVHC
- Date Format :
- YY-MM-DD-dd
- Terminal Position :
- Dual
- Volatile :
- No
- Width :
- 18.34mm
- Time Format :
- HH:MM:SS (24 hr)
- Packaging :
- Tube
- RAM (words) :
- 2040
- Current - Timekeeping (Max) :
- 3mA @ 4.5V~5.5V
- Datasheets
- M48T12-150PC1
M48T12-150PC1 Documents
Real Time Clocks STMicroelectronics M48T12-150PC1 Overview
The M48T12-150PC1 by STMicroelectronics is a robust real time clock (RTC) and calendar IC, integrated within a 24-pin DIP package. Designed to effectively manage date and time information with high accuracy and minimal power consumption, this device is crucial for applications requiring reliable timekeeping over extended periods. The M48T12-150PC1 is distinguished by its built-in 32.768 kHz oscillator and a pre-installed lithium battery which ensures up to 10 years of backup capability, making it an ideal choice for long-lasting, maintenance-free operations. Its straightforward parallel interface facilitates easy integration into existing systems, supporting a wide range of industrial and consumer applications.
M48T12-150PC1 Features
This IC features a 32.768 kHz quartz crystal oscillator, a self-contained power supply which allows it to maintain accurate timekeeping for up to a decade without external power. It also includes 114 bytes of NV RAM, offering extra storage for critical data which needs to be preserved during power loss. Additional features include automatic leap year compensation up to the year 2099, programmable alarm and interrupt functions, and a serial bus interface for easy programming and data communication.
