M40-4010246R

Manufacturer :

Harwin

Product Category :

Headers, Male Pins

Contact Type :

Male Pin

Connector Type :

Header

Insulation Color :

Natural

Orientation :

RIGHT ANGLE

Style :

Board to Cable/Wire

Mounting Type :

Surface Mount, Right Angle

Max Current Rating :

1A

IEC Conformance :

No

Mixed Contacts :

No

JESD-609 Code :

e3

DIN Conformance :

No

Depth :

5mm

Number of Rows :

1

Factory Lead Time :

13 Weeks

Operating Temperature :

-25°C~85°C

Termination :

Solder

Option :

GENERAL PURPOSE

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Package / Case :

SIL

Number of Positions :

2

MIL Conformance :

No

Pitch - Mating :

0.039 1.00mm

Contact Resistance :

30mOhm

RoHS Status :

ROHS3 Compliant

Radiation Hardening :

No

Packaging :

Tape and Reel (TR)

Number of Positions Loaded :

All

Insulation Height :

0.114 2.90mm

Contact Finish - Mating :

Tin

Fastening Type :

Push-Pull

Series :

M40

Max Voltage Rating (AC) :

50V

Insulation Material :

Polyamide (PA9T), Nylon 9T

Length :

3mm

Filter Feature :

No

Pbfree Code :

yes

Material Flammability Rating :

UL94 V-0

UL Flammability Code :

94V-0

Housing Material :

Nylon

Feature :

Solder Retention

Contact Shape :

RECTANGULAR

Contact Material :

Phosphor Bronze

Voltage - Rated :

50V

Total Number of Contacts :

2

Shrouding :

Shrouded - 4 Wall
