EEF-CD0K8R2R

Manufacturer :

Panasonic

Product Category :

Aluminum - Polymer Capacitors

Voltage - Rated AC :

8V

Type :

Polymer

Terminal Finish :

Tin (Sn)

Depth :

4.3mm

Rated (DC) Voltage (URdc) :

8V

Packaging :

Tape and Reel (TR)

Polarity :

POLARIZED

Termination :

SMD/SMT

Pbfree Code :

yes

Number of Terminations :

2

Height :

1.8mm

Dissipation Factor :

0.06 %

Capacitance :

8.2μF

Applications :

GENERAL PURPOSE

Moisture Sensitivity Level (MSL) :

3 (168 Hours)

JESD-609 Code :

e3

Case Code (Imperial) :

2917

Ripple Current :

1.4A

ESR (Equivalent Series Resistance) :

55mOhm

Tolerance :

±20%

Terminal Shape :

WRAPAROUND

Operating Temperature :

-40°C~105°C

Factory Lead Time :

14 Weeks

Voltage - Rated DC :

8V

Series :

SP-Cap CD

Packing Method :

Bulk

Length :

7.3mm

Leakage Current :

3μA

ECCN Code :

EAR99

Case Code (Metric) :

7343

Resistance :

55mOhm

Lead Free :

Lead Free

Package / Case :

2917 (7343 Metric)

Lifetime @ Temp :

1000 Hrs @ 105°C

Mount :

Surface Mount

Life (Hours) :

1000 hours

Radiation Hardening :

No

Height Seated (Max) :

0.075 1.90mm

Mounting Type :

Surface Mount

RoHS Status :

RoHS Compliant

Surface Mount Land Size :

0.287Lx0.169W 7.30mmx4.30mm

Size / Dimension :

0.287Lx0.169W 7.30mmx4.30mm

Published :

2011
