PQAE50-D48-S3-T

Manufacturer :

Bel

Product Category :

Voltage - Output 3 :

-

Voltage - Output 4 :

-

Typical Standby Current (mA) :

2

Product Category :

Isolated DC/DC Converters - Chassis Mount

Switching Frequency (kHz) :

300(Typ)

Minimum Input Voltage (V) :

36

Mounting Type :

Chassis Mount

Subcategory :

DC-DC Converter

Height :

21.2 mm

Product Status :

Active

Applications :

ITE (Commercial)

Efficiency :

91%

Product Weight (g) :

65

PCB changed :

6

Input/Output Type :

DC/DC

Output Type :

FIXED

Minimum Operating Temperature :

- 40 C

Voltage - Input (Max) :

75V

Power (Watts) :

33W

Efficiency (%) :

91(Typ)

Minimum Isolation Voltage :

1500VDC

Operating Temperature :

-40°C ~ 105°C (With Derating)

Switching Regulator :

yes

Pin Count :

6

Base Product Number :

PQAE50

Type :

Step Down

Isolation Voltage :

1.5 kV

Output Current (A) :

10

Product :

Isolated

Package Height :

21.2

Current - Output (Max) :

10A

RoHS Status :

RoHS Compliant

Maximum Operating Temperature :

+ 105 C

Output Power :

33 W

Product Type :

Isolated DC-DC Converters

Packaging :

Tray

Voltage - Output 1 :

3.3V

Number of Outputs :

1

Package Length :

76

Maximum Input Voltage (V) :

75

Mounting :

Chassis

Series :

PQAE50-T

Typical Input Voltage (V) :

48

Voltage - Output 2 :

-

Input Voltage :

36 V to 75 V

Voltage - Isolation :

1.5 kV

Voltage - Input (Min) :

36V

On/Off Logic :

Positive

Isolation :

Isolated

Package Width :

31.5

Width :

31.5 mm

Minimum Operating Temperature (°C) :

-40

Brand :

CUI Inc.

Output Power (W) :

33

Length :

76 mm

Size / Dimension :

2.99 L x 1.24 W x 0.83 H (76.0mm x 31.5mm x 21.2mm)

Standard Number :

62368-1

Package :

Tray

Approval Agency :

CE

Maximum Operating Temperature (°C) :

105

Manufacturer :

CUI Inc.

Line Regulation :

0.5%

Mounting Style :

Chassis

ECCN (US) :

EAR99

Load Regulation :

1%

RoHS :

Details

Output Voltage (V) :

3.3
