PQAE50-D24-S3-DIN

Manufacturer :

Bel

Product Category :

Input Voltage :

18 V to 36 mm

Input Type :

DC

Voltage - Output 6 :

-

Voltage - Output 1 :

3.3V

Package Length :

25.8

Product Status :

Active

Approval Agency :

CE

Product Weight (g) :

85

Isolation :

Isolated

Width :

31.5 mm

Voltage - Output 2 :

-

Switching Frequency (kHz) :

300(Typ)

Product Category :

Isolated DC/DC Converters - DIN Rail Mount

Output Voltage (V) :

3.3

Features :

Adjustable Output, Remote On/Off

Output Power (W) :

33

Minimum Input Voltage (V) :

18

Mounting :

DIN Rail

Manufacturer :

CUI Inc.

Power (Watts) :

33W

Package :

Tray

Package Height :

76

RoHS Status :

RoHS Compliant

Output Current (A) :

10

Maximum Operating Temperature (°C) :

105

Switching Regulator :

yes

Number of Outputs :

1

Minimum Load Required :

-

PCB changed :

6

Typical Standby Current (mA) :

6

Minimum Operating Temperature (°C) :

-40

Pin Count :

6

Brand :

CUI Inc.

Line Regulation :

0.5%

Current - Output (Max) :

10A

Typical Input Voltage (V) :

24

Size / Dimension :

2.99 L x 1.24 W x 1.02 H (76.0mm x 31.5mm x 25.8mm)

Type :

Step Down

Base Product Number :

PQAE50

Voltage - Output 4 :

-

Voltage - Isolation :

1.5 kV

On/Off Logic :

Positive

Maximum Operating Temperature :

+ 105 C

Load Regulation :

1%

Output Power :

33 W

Maximum Input Voltage (V) :

36

Isolation Voltage :

1.5 kV

Product Type :

Isolated DC-DC Converters

Efficiency :

91%

Packaging :

Tray

RoHS :

Details

Product :

Isolated

Voltage - Output 5 :

-

Voltage - Output 3 :

-

Length :

76 mm

Subcategory :

DC-DC Converter

Mounting Style :

DIN Rail

ECCN (US) :

EAR99

Applications :

ITE (Commercial)

Height :

25.8 mm

Package Width :

31.5

Minimum Isolation Voltage :

1500VDC

Minimum Operating Temperature :

- 40 C

Standard Number :

62368-1

Output Type :

FIXED

Efficiency (%) :

91(Typ)

Input/Output Type :

DC/DC

Series :

PQAE50-DIN

Operating Temperature :

-40°C ~ 105°C (With Derating)
