HTSW-208-07-SM-D

Manufacturer :

Samtec, Inc.

Product Category :

Headers, Male Pins

Moisture Sensitivity Level (MSL) :

Not Applicable

Row Spacing - Mating :

0.100 (2.54mm)

Contact Type :

Male Pin

Terminal Pitch :

5.08mm

Termination :

Solder

Overall Contact Length :

0.430 10.92mm

Reliability :

COMMERCIAL

Mount :

Through Hole

Contact Shape :

Square

Contact Finish - Mating :

Gold

Contact Material :

Phosphor Bronze

Mixed Contacts :

No

HTS Code :

8536.69.40.40

Number of Rows :

2

Contact Length - Post :

0.100 2.54mm

UL Flammability Code :

94V-0

Body Depth :

0.1 inch

IEC Conformance :

No

Contact Length - Mating :

0.230 5.84mm

Option :

GENERAL PURPOSE

Packaging :

Bulk

Operating Temperature :

-55°C~125°C

Connector Type :

Header

Insulation Height :

0.100 2.54mm

Contact Finish - Post :

Tin

Number of Conductors :

ONE

PCB Contact Pattern :

RECTANGULAR

Style :

Board to Board or Cable

Number of Positions Loaded :

All

ECCN Code :

EAR99

Factory Lead Time :

3 Weeks

Number of Positions :

16

Pitch - Mating :

0.200 5.08mm

MIL Conformance :

No

Fastening Type :

Push-Pull

Filter Feature :

No

Current Rating (Amps) :

Varies by WireGAuge

Contact Finish Thickness - Mating :

30.0μin 0.76μm

RoHS Status :

ROHS3 Compliant

Shrouding :

Unshrouded

Gender :

Male

Number Of PCB Rows :

2

Material Flammability Rating :

UL94 V-0

Series :

HTSW

Body Length or Diameter :

1.5 inch

DIN Conformance :

No

Insulation Material :

Liquid Crystal Polymer (LCP)

Insulation Color :

Natural

Body Breadth :

0.198 inch

Mounting Type :

Through Hole
