FSB70450

Manufacturer :

Fairchild Semiconductor

Product Category :

Power Driver Modules

Qualification Status :

Not Qualified

Drain to Source Resistance :

1.9Ohm

Published :

2016

Number of Terminations :

27

Max Collector Current :

4.8A

Weight :

2.174663g

Height :

1.4mm

Number of Pins :

27

Lifecycle Status :

ACTIVE (Last Updated: 1 day ago)

Reach Compliance Code :

not_compliant

Configuration :

3 Phase

ECCN Code :

EAR99

Output Current :

4.8A

Package / Case :

27-PowerLQFN Module

Pbfree Code :

yes

Frequency :

15kHz

Voltage - Isolation :

1500Vrms

Mounting Type :

Surface Mount

HTS Code :

8541.29.00.95

Max Operating Temperature :

150°C

Max Current Rating :

4.8A

Power Supplies :

15V

Switching Frequency :

15kHz

Max Power Dissipation :

110W

Width :

13mm

Collector Emitter Voltage (VCEO) :

500V

Packaging :

Tape and Reel (TR)

Operating Supply Current :

1.7mA

Time@Peak Reflow Temperature-Max (s) :

NOT SPECIFIED

Operating Supply Voltage :

300V

Mount :

Surface Mount

Max Supply Voltage :

400V

Series :

Motion SPM® 7

Terminal Finish :

Tin (Sn)

RoHS Status :

ROHS3 Compliant

Factory Lead Time :

6 Weeks

Number of Outputs :

3

Min Breakdown Voltage :

500V

Type :

MOSFET

Supply Voltage :

15V

Peak Reflow Temperature (Cel) :

260

Min Operating Temperature :

-40°C

JESD-609 Code :

e3

Moisture Sensitivity Level (MSL) :

3 (168 Hours)

Length :

13mm
