IGCM10F60GAXKMA1
Or copy the link below:
- Mfr.Part #
- IGCM10F60GAXKMA1
- Manufacturer
- Infineon Technologies
- Package / Case
- 24-PowerDIP Module (1.028, 26.10mm)
- Datasheet
- Download
- Description
- IGBT 600V 24MDIP
- Stock
- 15,831
- In Stock ：
- 15,831
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Infineon Technologies
- Product Category :
- Power Driver Modules
- Package / Case :
- 24-PowerDIP Module (1.028, 26.10mm)
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Peak Reflow Temperature (Cel) :
- NOT SPECIFIED
- Lead Free :
- Lead Free
- Max Operating Temperature :
- 150°C
- Published :
- 2015
- Height Seated (Max) :
- 5.6mm
- Terminal Position :
- Dual
- Factory Lead Time :
- 20 Weeks
- Time@Peak Reflow Temperature-Max (s) :
- NOT SPECIFIED
- Temperature Grade :
- Industrial
- Width :
- 21mm
- Type :
- IGBT
- Length :
- 36mm
- Supply Voltage-Min (Vsup) :
- 14V
- Output Voltage :
- 600V
- RoHS Status :
- ROHS3 Compliant
- Mount :
- Through Hole
- Output Current :
- 10A
- Supply Voltage-Max (Vsup) :
- 18.5V
- Number of Functions :
- 1
- Number of Pins :
- 24
- Supply Voltage :
- 16V
- Halogen Free :
- Halogen Free
- Series :
- CIPOS™
- Mounting Type :
- Through Hole
- Current Rating :
- 10A
- Voltage - Isolation :
- 2000Vrms
- Pbfree Code :
- yes
- Min Operating Temperature :
- -40°C
- Configuration :
- 3 Phase
- Number of Terminations :
- 24
- Datasheets
- IGCM10F60GAXKMA1
