BC546ABK

Manufacturer :

Diotec Semiconductor

Product Category :

Transistors - Bipolar (BJT) - Single

Lead Shape :

Through Hole

Minimum Operating Temperature (°C) :

-55

Maximum Collector-Emitter Voltage (V) :

65

ECCN (US) :

EAR99

PPAP :

No

Maximum Base Emitter Saturation Voltage (V) :

0.9(Typ)@5mA@100mA|0.7(Typ)@0.5mA@10mA

Packaging :

Bulk

Maximum Collector Base Voltage (V) :

80

Supplier Package :

TO-92

Automotive :

No

Maximum Power Dissipation (mW) :

500

Package Height :

4.6

Minimum DC Current Gain :

110@2mA@5V

Pin Count :

3

Maximum Emitter Base Voltage (V) :

5

Type :

NPN

EU RoHS :

Compliant

Standard Package Name :

TO-92

Configuration :

Single

Maximum Transition Frequency (MHz) :

300(Typ)

Maximum Operating Temperature (°C) :

150

Material :

Si

Package Length :

4.6

Mounting :

Through Hole

Maximum Collector-Emitter Saturation Voltage (V) :

@10mA|0.6@5mA@100mA

Number of Elements per Chip :

1

Maximum DC Collector Current (A) :

0.1

Category :

Bipolar Small Signal

PCB changed :

3

HTS :

8541.21.00.75
