BA4425F-E2

Manufacturer :

ROHM Semiconductor

Product Category :

RF Front End (LNA + PA)

Supply Voltage-Max (Vsup) :

6V

Terminal Finish :

TIN/TIN COPPER

Number of Functions :

1

Package / Case :

8-SOIC (0.173, 4.40mm Width)

Feature :

TV Front End

Pbfree Code :

yes

Published :

1999

Operating Temperature (Max) :

75°C

Pin Count :

8

Time@Peak Reflow Temperature-Max (s) :

10

JESD-609 Code :

e3/e2

Built-in IF Amplifier :

yes

Width :

6.2mm

Qualification Status :

Not Qualified

Terminal Position :

Dual

Number of Pins :

8

Surface Mount :

yes

Consumer IC Type :

AUDIO TUNER

Temperature Grade :

COMMERCIAL EXTENDED

Thickness :

1.5mm

Packaging :

Tape and Reel (TR)

Terminal Pitch :

1.27mm

Length :

5mm

Supply Voltage-Min (Vsup) :

1.6V

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

RF Type :

FM

Height Seated (Max) :

1.6mm

RoHS Status :

ROHS3 Compliant

ECCN Code :

EAR99

Supply Current-Max :

7.2mA

Peak Reflow Temperature (Cel) :

260

Operating Temperature (Min) :

-25°C

Lead Free :

Lead Free

Number of Bands :

1

Number of Terminations :

8

Terminal Form :

Gull wing
