B82472P6472M000

Manufacturer :

EPCOS (TDK)

Product Category :

Fixed Inductors

Military Standard :

Not

Packing Method :

TR, BLISTER, 13 INCH

HTS Code :

8504.50.80.00

Weight :

1.500002g

DC Resistance (DCR) - Parallel :

33mOhm

Inductance Tolerance :

20%

Operating Temperature (Min) :

-55°C

Inductor Application :

POWER INDUCTOR

Current Rating :

2.5A

Pbfree Code :

yes

Number of Terminations :

2

Inductor Type :

GENERAL PURPOSE INDUCTOR

Terminal Finish :

Tin (Sn) - with Nickel (Ni) barrier

Operating Temperature (Max) :

150°C

Max DC Current :

2A

Resistance :

33mOhm

Length :

7.5mm

RoHS Status :

RoHS Compliant

Shielding :

Shielded

Terminal Placement :

DUAL ENDED

Inductance :

4.7 µH

Shape/Size Description :

RECTANGULAR PACKAGE

Surface Mount :

yes

Depth :

7.5mm

ECCN Code :

EAR99

Test Frequency :

100kHz

Number of Functions :

1

Tolerance :

20%

REACH SVHC :

No SVHC

JESD-609 Code :

e3

Material - Core :

Ferrite

Number of Pins :

2

Lifecycle Status :

Production (Last Updated: 1 month ago)

DC Current :

2.5A

Inductance-Nom (L) :

4.7 µH

Terminal Shape :

WRAPAROUND

Package / Case :

SMD/SMT
