ACM22DSEH
Or copy the link below:
- Mfr.Part #
- ACM22DSEH
- Manufacturer
- Sullins Connector Solutions
- Package / Case
- Datasheet
- Download
- Description
- CONN EDGE DUAL FMALE 44POS 0.156
- Stock
- 2,530
- In Stock ：
- 2,530
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Sullins Connector Solutions
- Product Category :
- Edgeboard Connectors
- Length - Termination :
- 0.186 inch
- Number of Rows :
- 2
- Termination :
- Solder Eyelet(s)
- Published :
- 2005
- Packaging :
- Tray
- Insulation Resistance :
- 5000000000Ohm
- Mount :
- Panel
- Contact Material :
- BERYLLIUM COPPER
- Factory Lead Time :
- 3 Weeks
- Read Out :
- Dual
- Number of Positions :
- 44
- Voltage - Rated :
- 950V
- Flange Feature :
- Top Mount Opening, Unthreaded, 0.125 (3.18mm) Dia
- Operating Temperature :
- -65°C~150°C
- Mounting Type :
- Panel Mount
- Total Number of Contacts :
- 44
- Material - Insulation :
- Polyphenylene Sulfide (PPS)
- Reference Standard :
- UL
- Gender :
- FEMALE
- Reliability :
- COMMERCIAL
- Plating Thickness :
- 30μin
- Connector Type :
- Full Bellows
- Rated Current (Signal) :
- 5A
- Card Thickness :
- 0.062 1.57mm
- Body Depth :
- 0.431 inch
- Lead Free :
- Lead Free
- JESD-609 Code :
- e3
- Contact Finish Thickness :
- 30.0μin 0.76μm
- Moisture Sensitivity Level (MSL) :
- Not Applicable
- Card Type :
- Non Specified - Dual Edge
- Contact Type :
- Full Bellows
- Current Rating :
- 3A
- RoHS Status :
- ROHS3 Compliant
- Color :
- Green
- Contact Finish :
- Gold
- Pitch :
- 0.156 3.96mm
- Number of Positions/Bay/Row :
- 22
- Datasheets
- ACM22DSEH
