284509-3

Manufacturer :

TE Connectivity AMP Connectors

Product Category :

Headers, Plugs and Sockets

Material Flammability Rating :

UL94 V-0

Number of Ways :

13

Voltage - Rated AC :

300V

Max Current Rating :

11A

Wire Gauge or Range - mm² :

0.05-3mm2

Series :

Buchanan

Radiation Hardening :

No

ELV :

Compliant

Type :

Plug, Female Sockets

Operating Temperature :

-40°C~110°C

Voltage :

150V

Mounting Type :

Free Hanging (In-Line)

Termination :

Screw

Current :

12A

Wire Gauge (Min) :

14 AWG

Feature :

Interlocking (Side)

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Voltage - Rated :

300V

Lifecycle Status :

ACTIVE (Last Updated: 3 days ago)

Pitch :

0.150 3.81mm

Color :

Green

Additional Feature :

POLARIZATION AVAILABLE

Wire Strip Length :

5-6mm

Contact Mating Finish :

Tin

Termination Style :

Screw - Rising Cage Clamp

RoHS Status :

RoHS Compliant

Number of Contacts :

3

Safety Approval :

UL

Number of Levels :

1

Insulation Height :

0.437 11.10mm

Connector Type :

PLUG

Number of Rows :

1

Wire Gauge (Max) :

30 AWG

ECCN Code :

EAR99

Plug Wire Entry :

180°

Contact Material :

Phosphor Bronze

Wire Gauge or Range - AWG :

14-30 AWG

Orientation :

RIGHT ANGLE

Flammability Rating :

UL94 V-0

Lead Free :

Not Applicable

Screw Size :

M2

Published :

2007

Packaging :

Bulk

Number of Decks :

1

Mount :

Cable, Free Hanging

Current Rating :

11A

Torque - Screw :

0.25 Nm (2.2 Lb-In)

Housing Material :

Polyamide (PA66), Nylon 6/6

Factory Lead Time :

15 Weeks
