284506-7
Or copy the link below:
- Mfr.Part #
- 284506-7
- Manufacturer
- TE Connectivity AMP Connectors
- Package / Case
- Datasheet
- Download
- Description
- TERM BLOCK PLUG 7POS STR 3.5MM
- Stock
- 1,120
- In Stock ：
- 1,120
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- TE Connectivity AMP Connectors
- Product Category :
- Headers, Plugs and Sockets
- Max Supply Voltage (AC) :
- 300V
- Max Current Rating :
- 11A
- Radiation Hardening :
- No
- Thread Size :
- M2
- Voltage - Rated AC :
- 300V
- Number of Levels :
- 1
- Contact Material :
- Phosphor Bronze
- Termination Style :
- Screw - Rising Cage Clamp
- Flammability Rating :
- UL94 V-0
- Wire Gauge or Range - AWG :
- 14-30 AWG
- Torque - Screw :
- 0.31 Nm (2.7 Lb-In)
- Mount :
- Through Hole
- Wire Gauge (Min) :
- 30 AWG
- Contact Mating Finish :
- Tin
- Lead Free :
- Not Applicable
- Pitch :
- 0.138 3.50mm
- Series :
- Buchanan
- Orientation :
- RIGHT ANGLE
- Number of Contacts :
- 7
- Factory Lead Time :
- 15 Weeks
- Screw Size :
- M2
- Max Operating Temperature :
- 105°C
- Current Rating :
- 11A
- Operating Temperature :
- -40°C~110°C
- Feature :
- Side Stacking
- Material Flammability Rating :
- UL94 V-0
- Current :
- 11A
- Voltage :
- 300V
- Termination :
- Solder
- Lifecycle Status :
- ACTIVE (Last Updated: 2 days ago)
- Voltage - UL :
- 300V
- Voltage - Rated :
- 300V
- Packaging :
- Bulk
- Moisture Sensitivity Level (MSL) :
- 1 (Unlimited)
- Max Voltage Rating (AC) :
- 300V
- Length :
- 24.5mm
- Published :
- 2007
- Housing Color :
- Green
- Connector Type :
- PLUG
- Min Operating Temperature :
- -40°C
- Housing Material :
- Polyamide (PA66), Nylon 6/6
- Insulation Height :
- 0.437 11.10mm
- Number of Positions :
- 7
- Plug Wire Entry :
- 180°
- Number of Circuits :
- 7
- Wire Gauge or Range - mm² :
- 0.05-3mm2
- Positions Per Level :
- 7
- Contact Plating :
- Tin
- Wire Gauge (Max) :
- 30 AWG
- Color :
- Green
- Depth :
- 15.5mm
- Current - UL :
- 11A
- Mounting Type :
- Free Hanging (In-Line)
- Number of Positions Per Level :
- 7
- RoHS Status :
- RoHS Compliant
- ELV :
- Compliant
- Wire Strip Length :
- 5-6mm
- Number of Rows :
- 1
- Type :
- Plug, Female Sockets
- Datasheets
- 284506-7
Bulk 0.138 3.50mm Green 1 Levels Free Hanging (In-Line) Plug, Female Sockets Buchanan Polyamide (PA66), Nylon 6/6 Tin Phosphor Bronze
284506-7 Overview
Currently, it is packaged in Plug.The mounting type of the device is Free Hanging (In-Line).A Bulk case is used to package the product.A product of the Buchanan Series, it belongs to the range of products of that series.A temperature below 105°C is best for using it.The device must run at -40°C degrees.A number of features make the Side Stacking feature more powerful.Through Hole represents the mounting point for the part.Contains 7 circuits.-40°C~110°C Operating Temperature is the default operating temperature for the device.As with other Plug, Female Sockets products, this part also offers a wide range of benefits.
