284509-2

Manufacturer :

TE Connectivity AMP Connectors

Product Category :

Headers, Plugs and Sockets

Flammability Rating :

UL94 V-0

Packaging :

Bulk

Material Flammability Rating :

UL94 V-0

Insulation Height :

0.437 11.10mm

Max Current Rating :

11A

RoHS Status :

RoHS Compliant

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Mount :

Cable, Free Hanging

Additional Feature :

POLARIZATION AVAILABLE

Voltage - Rated :

300V

Voltage :

150V

Housing Material :

Polyamide (PA66), Nylon 6/6

Termination Style :

Screw - Rising Cage Clamp

Screw Size :

M2

Voltage - Rated AC :

300V

ECCN Code :

EAR99

Current Rating :

11A

Wire Gauge (Min) :

14 AWG

Operating Temperature :

-40°C~110°C

Radiation Hardening :

No

Number of Decks :

1

Number of Ways :

22

Termination :

Screw

Plug Wire Entry :

180°

Feature :

Interlocking (Side)

Published :

2007

Contact Mating Finish :

Tin

Wire Gauge or Range - AWG :

14-30 AWG

Wire Gauge or Range - mm² :

0.05-3mm2

Type :

Plug, Female Sockets

Color :

Green

Lifecycle Status :

ACTIVE (Last Updated: 2 weeks ago)

Wire Gauge (Max) :

30 AWG

Mounting Type :

Free Hanging (In-Line)

Number of Contacts :

2

ELV :

Compliant

Wire Strip Length :

5-6mm

HTS Code :

8536.69.40.40

Safety Approval :

UL

Lead Free :

Not Applicable

Pitch :

0.150 3.81mm

Orientation :

RIGHT ANGLE

Number of Levels :

1

Connector Type :

PLUG

Torque - Screw :

0.25 Nm (2.2 Lb-In)

Number of Rows :

1

Factory Lead Time :

15 Weeks

Current :

12A

Series :

Buchanan

Contact Material :

Phosphor Bronze
