QH12TZ600

Manufacturer :

Power Integrations

Product Category :

Diodes - Rectifiers - Single

Package / Case :

TO-220-2

Pin Count :

3

Voltage - Forward (Vf) (Max) @ If :

3.1V @ 12A

Diode Type :

Standard

Min Operating Temperature :

-55°C

Element Configuration :

Single

Number of Phases :

1

Application :

EFFICIENCY

Diode Element Material :

SILICON

Speed :

Fast Recovery =< 500ns, > 200mA (Io)

Forward Current :

12A

Average Rectified Current :

12A

Power Dissipation :

61W

Number of Elements :

1

Radiation Hardening :

No

Current - Reverse Leakage @ Vr :

250μA @ 600V

Peak Reverse Current :

250μA

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Max Operating Temperature :

150°C

Peak Non-Repetitive Surge Current :

350A

Max Reverse Voltage (DC) :

600V

Recovery Time :

11.6 ns

Mount :

Through Hole

ECCN Code :

EAR99

Case Connection :

Isolated

RoHS Status :

RoHS Compliant

Max Repetitive Reverse Voltage (Vrrm) :

600V

Reverse Voltage :

600V

JESD-609 Code :

e3

Published :

2011

Terminal Finish :

MATTE TIN

Packaging :

Tube

Number of Pins :

2

Reverse Recovery Time :

11.6 ns

Operating Temperature - Junction :

150°C Max

HTS Code :

8541.10.00.80

Series :

Qspeed™

Mounting Type :

Through Hole

Factory Lead Time :

4 Weeks

Max Surge Current :

100A

Number of Terminations :

2
