PT19-21B/L41/TR8
Or copy the link below:
- Mfr.Part #
- PT19-21B/L41/TR8
- Manufacturer
- Everlight Electronics
- Package / Case
- 0603 (1608 Metric)
- Datasheet
- Download
- Description
- SENSOR PHOTO 940NM TOP VIEW 0603
- Stock
- 655,715
- In Stock ：
- 655,715
Request A Quote(RFQ)
- * Fullname:
- * Company:
- * E-Mail:
- Phone:
- Comment:
- * Quantity:
- Manufacturer :
- Everlight Electronics
- Product Category :
- Optical Sensors - Phototransistors
- Lens Color :
- Black
- Operating Temperature :
- -25°C~85°C TA
- Packaging :
- Tape and Reel (TR)
- Max Breakdown Voltage :
- 30V
- Orientation :
- Top View
- Factory Lead Time :
- 20 Weeks
- Polarity :
- NPN
- Optoelectronic Device Type :
- PHOTO TRANSISTOR
- Package / Case :
- 0603 (1608 Metric)
- Wavelength :
- 940nm
- Published :
- 2012
- Configuration :
- Single
- RoHS Status :
- ROHS3 Compliant
- Additional Feature :
- HIGH SENSITIVITY
- Light Current-Nom :
- 0.6mA
- Number of Functions :
- 1
- Shape :
- RECTANGULAR
- Rise Time :
- 15μs
- Collector Emitter Voltage (VCEO) :
- 5V
- Number of Elements :
- 1
- Lens Style :
- Flat
- Number of Pins :
- 2
- Collector Emitter Breakdown Voltage :
- 30V
- Mount :
- Surface Mount
- Fall Time (Typ) :
- 15 µs
- Pbfree Code :
- yes
- Mounting Type :
- Surface Mount
- Infrared Range :
- yes
- Power Dissipation :
- 75mW
- Max Collector Current :
- 20mA
- Dark Current :
- 100nA
- Moisture Sensitivity Level (MSL) :
- 3 (168 Hours)
- Datasheets
- PT19-21B/L41/TR8
