PC-120-8

Manufacturer :

Signal Transformer

Product Category :

Power Transformers

Primary Winding(s) :

Single

RoHS Status :

ROHS3 Compliant

Series :

PC

Published :

2009

Output Voltage 1 :

60V

Voltage - Secondary (Full Load) :

Parallel 60V Series 120V

Lead Free :

Lead Free

Approval Agency :

UL; CSA

VA Rating :

1 VA

Output Power :

1W

Voltage - Isolation :

1500Vrms

Current - Output (Max) :

Parallel 16mA Series 8mA

Operating Frequency-Max :

0.5kHz

Additional Feature :

OPERATING FREQUENCY: 50-500 HZ

Voltage - Primary :

115V

Power - Max :

1VA

Termination :

PC Pin

Output Voltage 2 :

60V

Secondary Winding(s) :

Dual

Moisture Sensitivity Level (MSL) :

Not Applicable

Max Power Dissipation :

1W

Center Tap :

No

Mounting Type :

Through Hole

Size / Dimension :

25.40mm Lx34.92mm W

Factory Lead Time :

18 Weeks

Termination Style :

PC Pin

Height Seated (Max) :

21.08mm

Length :

25.4mm

Mount :

Through Hole

HTS Code :

8504.31.40.35

Max Output Current :

8mA

Width :

34.92mm

Height :

21.1mm

Type :

Laminated Core

Operating Frequency-Min :

0.05kHz

Weight :

0.157lb 71.21g

ECCN Code :

EAR99
