MIC5205-2.5YM5TR

Manufacturer :

Micrel Inc.

Product Category :

Voltage Regulators - Linear

Output Current :

0.15 A

Mount :

Surface Mount

Min Input Voltage :

2.5V

Quiescent Current :

10 nA

Pbfree Code :

yes

Number of Terminals :

5

Radiation Hardening :

No

Factory Lead Time :

21 Weeks

Package / Case :

SC-74A, SOT-753

Output Voltage1-Nom :

2.5 V

Lead Free :

Lead Free

Number of Outputs :

1

JESD-30 Code :

R-PDSO-G5

Current - Quiescent (Iq) :

150μA

Number of Pins :

5

Width :

1.6mm

Length :

2.9mm

Tolerance :

1 %

Seated Height-Max :

1.45 mm

Voltage Tolerance-Max :

2%

Junction to Case :

130 °C/W

Load Regulation :

0.2 %

Maximum Input Voltage :

16 V

Dropout Voltage :

165mV

Product Type :

LDO Voltage Regulators

Power Supply Rejection Ratio (PSRR) :

75dB

Reach Compliance Code :

Compliant

Current - Supply (Max) :

2.5mA

RoHS Status :

ROHS3 Compliant

Supplier Device Package :

SOT-23-5

Output Voltage1-Max :

2.55 V

Subcategory :

PMIC - Power Management ICs

Input Voltage Range :

2.5 to 16 V

Terminal Position :

Dual

Dropout Voltage1-Nom :

0.165 V

Voltage - Output (Max) :

--

HTS Code :

8542.39.00.01

Brand :

Microchip Technology / Atmel

Package Shape :

RECTANGULAR

Control Features :

Enable

Regulator Type :

FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR

Package Type :

SOT-23

Operating Temperature TJ-Min :

-40 °C

Protection Features :

Over Current, Over Temperature, Reverse Polarity

Terminal Pitch :

0.95 mm

Maximum Operating Temperature :

+ 125 C

PSRR :

75dB (100Hz)

Base Product Number :

MIC5205

Minimum Operating Temperature :

- 40 C

Height :

1.1mm

Output Voltage :

2.5V

Surface Mount :

yes

Output Current1-Max :

0.15 A

Supplier Package :

SOT-23

JESD-609 Code :

e4

Mounting :

Surface Mount

Operating Temperature :

-40°C~125°C

Adjustability :

FIXED

Pin Count :

5

Termination :

SMD/SMT

Line Regulation :

0.012 %/V

Packaging :

Tape and Reel (TR)

Screening Level :

Extended Industrial

Qualification Status :

Not Qualified

Voltage - Output (Min/Fixed) :

2.5V

ECCN Code :

EAR99

Min Output Voltage :

2.5V

Junction to Ambient :

220 °C/W

Peak Reflow Temperature (Cel) :

260

Terminal Finish :

Nickel/Palladium/Gold (Ni/Pd/Au)

Product Category :

LDO Voltage Regulators

Min Supply Voltage :

2.5V

Output Voltage1-Min :

2.45 V

Function :

LDO

Current - Output :

150mA

Max Output Voltage :

2.5V

RoHS :

Details

Min Operating Temperature :

-40°C

Package :

Tape and Reel (TR);Cut Tape (CT);Digi-Reel®;

Max Supply Voltage :

16V

Manufacturer :

Microchip

Mounting Style :

SMD/SMT

Base Part Number :

MIC5205

Voltage - Input (Max) :

16V

Polarity :

Positive

Max Output Current :

150mA

MSL :

MSL 1 - Unlimited

Product Status :

Active

Operating Temperature TJ-Max :

125 °C

Output Type :

FIXED

Max Operating Temperature :

125°C

Terminal Form :

Gull wing

Output Configuration :

Positive

Number of Regulators :

1

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Packing Method :

Tape and Reel

Voltage Dropout (Max) :

0.35V @ 150mA

REACH SVHC :

No SVHC

Dropout Voltage1-Max :

0.35 V

Input Voltage Absolute-Max :

20 V

Series :

--

Accuracy :

1 %

Number of Functions :

1

Mounting Type :

Surface Mount

Max Input Voltage :

16V
