MIC5156YM-TR

Manufacturer :

Microchip Technology

Product Category :

Voltage Regulators - Linear Regulator Controllers

Voltage - Input :

3V ~ 36V

Qualification Status :

Not Qualified

Package Shape :

RECTANGULAR

Minimum Operating Temperature :

- 40 C

Min Input Voltage :

3V

Packaging :

Tape and Reel (TR)

Terminal Position :

Dual

JESD-609 Code :

e4

Operating Supply Current :

2.7mA

Analog IC - Other Type :

ANALOG CIRCUIT

Operating Temperature :

-40°C~85°C

Product Status :

Active

Min Operating Temperature :

-40°C

Subcategory :

PMIC - Power Management ICs

Current - Supply :

2.7mA

Type :

Positive Adjustable

Length :

4.93 mm

Temperature Grade :

Industrial

RoHS :

Details

Max Operating Temperature :

85°C

Peak Reflow Temperature (Cel) :

260

Product Type :

LDO Voltage Controllers

Supplier Device Package :

8-SOIC

Supply Voltage-Min (Vsup) :

3 V

Package :

Tape and Reel (TR)

Brand :

Microchip Technology

Surface Mount :

yes

Series :

-

Seated Height-Max :

1.73 mm

Output Voltage :

36V

Base Part Number :

MIC5156

Number of Pins :

8

RoHS Status :

ROHS3 Compliant

Reach Compliance Code :

Compliant

Number of Terminals :

8

Mounting Type :

Surface Mount

Output Type :

Adjustable

Maximum Operating Temperature :

+ 85 C

Terminal Finish :

Nickel/Palladium/Gold (Ni/Pd/Au)

Width :

3.94 mm

Mounting Style :

SMD/SMT

Number of Functions :

1

Package / Case :

8-SOIC (0.154, 3.90mm Width)

Factory Lead Time :

6 Weeks

Manufacturer :

Microchip

Product Category :

LDO Voltage Controllers

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

Supply Voltage-Max (Vsup) :

36 V

Base Product Number :

MIC5156

Max Input Voltage :

36V

Number of Outputs :

1

Terminal Pitch :

1.27 mm

JESD-30 Code :

R-PDSO-G8

HTS Code :

8542.39.00.01

Terminal Form :

Gull wing
