MCP4361-104E/ML

Manufacturer :

Microchip Technology

Product Category :

Digital Potentiometers

Published :

2009

Temperature Grade :

Automotive

Peak Reflow Temperature (Cel) :

260

Features :

-

Resistance - Wiper (Ω) (Typ) :

75

Power Supplies :

3/5V

Number of Circuits :

4

Base Part Number :

MCP4361

Width :

4mm

Supplier Device Package :

20-QFN (4x4)

Product Type :

Digital Potentiometer ICs

Control Interface :

Serial SPI

Number of Positions :

257

Voltage - Supply :

1.8V~5.5V

Packaging :

Tube

Operating Supply Current :

0.55 mA

Brand :

Microchip Technology

Length :

4mm

Terminal Position :

QUAD

Mounting Style :

PCB Mount

Termination Style :

SMD/SMT

Resistance :

100kOhm

Mounting Type :

Surface Mount

Terminal Form :

NO LEAD

RoHS Status :

ROHS3 Compliant

Product Status :

Active

Reach Compliance Code :

Compliant

Converter Type :

DIGITAL POTENTIOMETER

Moisture Sensitivity Level (MSL) :

1 (Unlimited)

HTS Code :

8542.39.00.01

JESD-30 Code :

S-PQCC-N20

Interface :

SPI

Maximum Operating Temperature :

+ 125 C

Bandwidth :

0.1 kHz

Supplier Package :

QFN EP

Mounting :

Surface Mount

ECCN Code :

EAR99

Package :

Tube

Number of Terminations :

20

Product Category :

Digital Potentiometer ICs

Series :

WiperLock™

JESD-609 Code :

e3

Number of Pot per Package :

4

Supply Voltage :

2.7V

Operating Temperature :

-40°C~125°C

Temperature Coefficient (Typ) :

150ppm/°C

Mount :

Surface Mount

Number of Terminals :

20

Configuration :

Potentiometer

Number of Taps :

257

Resistance Law :

Linear

Manufacturer :

Microchip

Factory Lead Time :

15 Weeks

Base Product Number :

MCP4361

Memory Type :

Non-Volatile

Nominal Supply Current :

450μA

Resistance (Ohms) :

100k

Pbfree Code :

yes

Power Supply Type :

Single

Minimum Operating Temperature :

- 40 C

Qualification Status :

Not Qualified

Number of Functions :

4

Screening Level :

Extended

Taper Type :

Linear

Radiation Hardening :

No

Number of Pins :

20

Qualification :

AEC-Q100

Pin Count :

20

Taper :

Linear

Temperature Coefficient :

150 ppm/°C

Terminal Pitch :

0.5mm

Operating Supply Voltage :

5.5, 1.8 V

Terminal Finish :

Matte Tin (Sn) - annealed

Time@Peak Reflow Temperature-Max (s) :

40

Package Shape :

Square

Height :

950μm

RoHS :

Details

Subcategory :

Digital Potentiometer ICs

Surface Mount :

yes

Total Resistance :

100000Ohm

Package / Case :

20-VFQFN Exposed Pad

Seated Height-Max :

1 mm

Tolerance :

±20%

Resistor Terminal Voltage-Max :

5.5V
