MCC56-12IO1B

Share

Or copy the link below:

Mfr.Part #
MCC56-12IO1B
Manufacturer
Littelfuse
Package / Case
TO-240AA
Datasheet
Download
Description
MOD THYRISTOR DUAL 1200V TO240AA
Stock
174
In Stock :
174

Request A Quote(RFQ)

* Fullname:
* Company:
* E-Mail:
  Phone:
  Comment:
* Quantity:
Manufacturer :
Littelfuse
Product Category :
Thyristors - SCRs - Modules
On-State Current-Max :
60000A
Number of Elements :
2
JESD-30 Code :
R-XUFM-X7
Number of Pins :
7
RoHS :
Details
Product Type :
Discrete Semiconductor Modules
Max Repetitive Reverse Voltage (Vrrm) :
1.2kV
Reach Compliance Code :
Compliant
RMS Current (Irms) :
100A
Packaging :
Bulk
Vf - Forward Voltage :
1.24 V
Type :
Phase Leg
Reverse Voltage :
1.2kV
Configuration :
SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Dimensions :
92 x 20.8 x 30mm
Published :
2004
Pbfree Code :
yes
Current - On State (It (RMS)) (Max) :
100A
Hold Current :
200mA
Number of SCRs, Diodes :
2 SCRs
Trigger Device Type :
SCR
Non-Repetitive Pk On-state Cur :
1600 A
Length :
92mm
Package Type :
TO-240AA
Product :
Thyristor Power Modules
Brand :
IXYS
JEDEC-95 Code :
TO-240AA
RMS On-state Current-Max :
100 A
Mounting Type :
Chassis Mount
Mount :
Chassis Mount, Panel, Screw
Current - On State (It (AV)) (Max) :
64A
Base Part Number :
MC*56
Terminal Form :
UNSPECIFIED
Operating Temperature :
-40°C~125°C TJ
Surface Mount :
No
Current - Non Rep. Surge 50, 60Hz (Itsm) :
1500A 1600A
Package / Case :
TO-240AA
Moisture Sensitivity Level (MSL) :
1 (Unlimited)
Height :
30mm
Current - Hold (Ih) (Max) :
200mA
Pin Count :
7
Case Connection :
Isolated
Manufacturer :
IXYS
Number of Terminals :
7
Structure :
Series Connection - All SCRs
Desc. of Screw Terminals :
A-K-AK
Terminal Position :
UPPER
Qualification Status :
Not Qualified
Repetitive Peak Off-state Voltage :
1200V
Voltage - Gate Trigger (Vgt) (Max) :
1.5V
Factory Lead Time :
24 Weeks
Series :
--
Desc. of Quick-Connects :
2G-2GR
Radiation Hardening :
No
Package Shape :
RECTANGULAR
Minimum Operating Temperature :
-40 °C
Additional Feature :
UL RECOGNIZED
RoHS Status :
ROHS3 Compliant
Peak Reflow Temperature (Cel) :
NOT SPECIFIED
Current - Gate Trigger (Igt) (Max) :
100mA
Holding Current-Max :
200 mA
DC Gate Trigger Current-Max :
100 mA
Maximum Operating Temperature :
+125 °C
Mounting Style :
Screw Mounts
Package :
Bulk
Technology :
Si
Voltage - Off State :
1.2kV
HTS Code :
8541.30.00.80
Product Category :
Discrete Semiconductor Modules
Width :
20.8mm
Number of Terminations :
7
DC Gate Trigger Voltage-Max :
1.5 V
Repetitive Peak Reverse Voltage :
1200V
Lead Free :
Lead Free
Base Product Number :
MCC56
Product Status :
Active
Leakage Current (Max) :
15mA
Datasheets
MCC56-12IO1B
Introducing Thyristors - SCRs - Modules Littelfuse MCC56-12IO1B from Chip IC,where excellence meets affordability. This product stands out with its Number of Pins:7, Type:Phase Leg, Mounting Type:Chassis Mount, Base Part Number:MC*56, Operating Temperature:-40°C~125°C TJ, Package / Case:TO-240AA, Number of Terminations:7, MCC56-12IO1B pinout, MCC56-12IO1B datasheet PDF, MCC56-12IO1B amp .Beyond Thyristors - SCRs - Modules Littelfuse MCC56-12IO1B ,we also offer LS431650, MCC200-18IO1, MCC310-16IO1, Our vast inventory has you covered. Contact us now for immediate solutions.
