M80-8430445

Manufacturer :

Harwin

Product Category :

Headers, Male Pins

Plating Thickness :

30μin

Number of Positions :

4

Termination :

Solder

JESD-609 Code :

e4

Voltage - Rated :

120V

Option :

GENERAL PURPOSE

Contact Length - Post :

0.118 3.00mm

RoHS Status :

ROHS3 Compliant

Insulation Color :

Black

PCB Contact Pattern :

RECTANGULAR

IEC Conformance :

No

Mounting Type :

Through Hole, Right Angle

Connector Type :

Header

ECCN Code :

EAR99

Style :

Board to Board or Cable

Filter Feature :

No

DIN Conformance :

No

Shrouding :

Shrouded - 4 Wall

Contact Material :

Phosphor Bronze

Durability :

500 Cycles

Number of Positions Loaded :

All

Insertion Force-Max :

2.78 N

Pitch - Mating :

0.079 2.00mm

Reliability :

COMMERCIAL

Terminal Pitch :

2mm

Contact Resistance :

25mOhm

Contact Shape :

Circular

Number of Rows :

1

Mating Contact Pitch :

0.079 inch

Mounting Option 1 :

LOCKING

Packaging :

Tube

Insulation Height :

0.156 3.96mm

Material Flammability Rating :

UL94 V-0

Series :

Datamate L-Tek

Mixed Contacts :

No

Current Rating (Amps) :

2.2A

Mating Information :

MULTIPLE MATING PARTS AVAILABLE

Insulation Material :

Polyamide (PA46), Nylon 4/6, Glass Filled

Number of Conductors :

ONE

Feature :

Strain Relief Clips

Reference Standard :

UL

Additional Feature :

RoHS Compliant

Contact Finish Thickness - Mating :

29.5μin 0.75μm

Contact Type :

Male Pin

Fastening Type :

Latch Holder

Operating Temperature :

-55°C~125°C

Number Of PCB Rows :

1

Contact Finish - Mating :

Gold

Pbfree Code :

yes

MIL Conformance :

No
