FKP2C012201D00HSSD

Manufacturer :

WIMA

Product Category :

Film Capacitors

Lead Diameter (nom) :

0.5(mm)

Lead Diameter (mm) :

0.5

Brand :

WIMA

Applications :

High Frequency, Switching; High Pulse, DV/DT

Terminal Pitch :

5 mm

Product Diameter (mm) :

Not Required(mm)

Product Status :

Active

Voltage :

40VAC|63VDC

Product Type :

Film Capacitors

Height - Seated (Max) :

0.236 (6.00mm)

RoHS :

Non-Compliant

Lead Length (mm) :

6

Reach Compliance Code :

Compliant

Diameter :

-

Operating Temperature :

-55°C ~ 100°C

Tolerance :

2.5%

ECCN (US) :

EAR99

Lead Diameter :

0.5 mm

Number of Pins :

2 Pin

Lead Style :

Straight

Terminal Shape :

Wire

Capacitance :

2200PF(pF)

ECCN Code :

EAR99

Positive Tolerance :

2.5%

Terminal Finish :

Tin (Sn)

JESD-609 Code :

e3

Lead Spacing :

5 mm

Rated (DC) Voltage (URdc) :

63 V

Mounting Feature :

THROUGH HOLE MOUNT

Series :

FKP 2

Subcategory :

Capacitors

Voltage Rating - AC :

40V

Rated (AC) Voltage (URac) :

40 V

Negative Tolerance :

2.5%

Maximum Operating Temperature (°C) :

100

Product Height (mm) :

6(Max)

Package Shape :

RECTANGULAR PACKAGE

Capacitance Value :

0.0022uF

Wire Form :

Straight

Mounting Style :

Through Hole

Manufacturer :

WIMA

Product Category :

Film Capacitors

Maximum Operating Temperature :

+ 100 C

Terminal Pitch (mm) :

5

Ratings :

-

Failure Rate :

Not Required

Type :

Pulse

Additional Feature :

RATED AC VOLTAGE (V): 40

Surface Mount :

No

Termination :

PC Pins

Construction :

Plastic Rectangular Can

RoHS Status :

RoHS Compliant

Minimum Operating Temperature (°C) :

-55

Pbfree Code :

yes

Operating Temp Range :

-55C to 100C

Number of Terminals :

2

Packaging :

Bulk

Seated Plane Height :

6(mm)

Minimum Operating Temperature :

- 55 C

Size Code :

2818

Dielectric :

PP

Package :

Bulk

Capacitor Type :

FILM CAPACITOR

Product Weight (g) :

0.313

Product Length (mm) :

7.2(Max)

Packing Method :

Bulk

Seated Plane Height (mm) :

6(Max)

Features :

-

Mounting Type :

Through Hole

HTS Code :

8532.25.00.70

Tolerance (+ or -) :

2.5%

Mounting :

Through Hole

Dielectric Material :

Polypropylene (PP)

Voltage Rating - DC :

63V

Size (mm) :

7.2 X 4.5 X 6

Size / Dimension :

0.283 L x 0.177 W (7.20mm x 4.50mm)

Product :

AC and Pulse Film Capacitors

Height :

6 mm

Temp Coeff (Dielectric) :

PP

Width :

4.5 mm

Product Depth (mm) :

4.5(Max)

Length :

7.2 mm

Package / Case :

Not Required

Termination Style :

Radial
