DPC-120-10

Manufacturer :

Signal Transformer

Product Category :

Power Transformers

Mount :

Through Hole

Max Power Dissipation :

1.2W

Power - Max :

1.2VA

Primary Winding(s) :

Dual

Number of Secondary Winding :

2

Center Tap :

No

Voltage - Secondary (Full Load) :

Parallel 60V Series 120V

Series :

DPC

Output Voltage 1 :

60V

RoHS Status :

ROHS3 Compliant

Additional Feature :

OPERATING FREQUENCY: 50-500 HZ

Mounting Type :

Through Hole

Operating Frequency-Min :

0.05kHz

Output Power :

1.2W

Termination :

PC Pin

VA Rating :

1.2 VA

Voltage - Isolation :

1500Vrms

Termination Style :

PC Pin

Height Seated (Max) :

30.15mm

Size / Dimension :

34.90mm Lx28.60mm W

Approval Agency :

UL; CSA

Max Output Current :

10mA

HTS Code :

8504.31.40.35

Lead Free :

Lead Free

ECCN Code :

EAR99

Width :

28.6mm

Output Voltage 2 :

60V

Operating Frequency-Max :

0.5kHz

Current - Output (Max) :

Parallel 20mA Series 10mA

Type :

Laminated Core

Moisture Sensitivity Level (MSL) :

Not Applicable

Voltage - Primary :

115V 230V

Published :

2009

Factory Lead Time :

18 Weeks

Weight :

0.188lb 85.28g

Height :

30.1mm

Length :

34.9mm
